- Main Processor
- Multi-core embedded processor
- Operating System
- Embedded LINUX
- Performance
- 12 channel, 10 IVS rules for each channel
- Object classification
- Human/Vehicle secondary recognition for tripwire and intrusion
- AI Search
- Search by target classification (Human, Vehicle)
- Performance
- Max 16 face pictures/sec processing (modeling and comparing)
- Stranger Mode
- Detect strangers’ faces (not in device’s face database).Similarity threshold can be set manually.
- AI Search
- Up to 8 target face images search at same time, similarity threshold can be set for each target face image.
- Database Capacity
- Up to 20 face databases with 200,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture.
- Database Application
- Each database can be applied to video channels independently.
- Trigger Events
- Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc.
- Face
- Gender, age, glasses, beard, mouth mask, expression.
- Vehicle
- Plate No., type, color, vehicle type, logo, plate color, ornament, calling, seatbelt, region.
- Human Body
- Top, top color, bottom, bottom color, hat, bag, gender, age, umbrella.
- Non-motor Vehicle
- Type, color, number of passengers, helmet.
- AI Search
- Support search target video by metadata.
- IP Camera Input
- 16 Channel
- Two-way Talk
- 1 Channel Input, 1 Channel Output, RCA
- Interface
- 1 HDMI, 1 VGA
- Resolution
- HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Decoding Capability
- 4-ch@8MP (30fps), 16-ch@1080P (30fps)
- Multi-screen Display
- 1/4/8/9/16
- Bandwidth
- 320 Mbps (160 Mbps when AI function enabled)
- Compression
- Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
- Resolution
- 24MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1 etc.
- Record Mode
- Manual, Schedule (Continuous, MD (Motion Detection), Alarm, IVS)
- Record Interval
- 1–120 min (default: 60 min), Pre-record: 1–30 sec, Post-record: 10–300 sec
- Trigger Events
- Alarm Out, Video Push, Email, Recording, PTZ, Tour, Snapshot, Voice Prompt, Buzzer, and Screen Tips
- Video Detection
- Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Scene Change
- Alarm input
- 4 Channel
- Relay Output
- 2 Channel
- Sync Playback
- 1/4/9/16
- Search Mode
- Time/Date, Alarm, MD and Exact Search (accurate to second)
- Backup Mode
- USB Device/Network
- Supported Brands
- Panasonic, Sony, Samsung, Axis, Pelco, Arecont, Onvif, Canon and more
- Interface
- 1 RJ-45 Ports (10/100/1000 Mbps)
- PoE
- 8 ports (IEEE802.3af/at) 1-8 ports support ePoE & EoC
- Network Protocol
- HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), P2P
- Max. User Access
- 128 users
- Mobile App
- iPhone, iPad, Android
- Interoperability
- ONVIF 2.4, SDK, CGI
- Internal HDD
- 2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
- eSATA
- N/A
- USB
- 2 USB Ports (1 Rear USB 3.0, 1 Front USB 2.0)
- RS232
- 1 Port, for PC Communication and Keyboard
- RS485
- 1 Port, for PTZ Control
- Power Supply
- Single, AC100V–240V, 50–60 Hz
- Power Consumption
- NVR: <15.6W (Without HDD), PoE: Max 25.5W for single port, 130W total rated power, 80% control for protection
- Fan
- Smart fan, automatically adjust running speed
- Operating Conditions
- –10°C to +55°C (+14°F to +131°F), 86–106kpa
- Storage Conditions
- 0°C to +40°C (+32°F to +104°F), 30–85% RH
- Dimensions
- 1U, 375.0 mm × 327.4 mm × 53.0 mm (14.76″ × 12.89″ × 2.09″)
- Net Weight
- 2.70 kg (6.0 lb) (without HDD)
- Gross Weight
- 4.00 kg (8.8 lb) (without HDD)
- CE
- EN55032, EN55024, EN50130-4, EN62368-1
- FCC
- Part 15 Subpart B, ANSI C63.4-2014
- UL
- UL 60950-1
- รหัสสินค้า (SKU)
- DHI-NVR5216-8P-I/L
