- Main Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- Operating Interface
- Web, Local GUI
- AI by Recorder
- SMD Plus
- AI by Camera
- Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
- Perimeter Performance of AI by Camera
- 6 channels
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- Face Detection Performance of AI by Camera
- 6 channels
- Face Recognition Performance of AI by Camera
- 6 channels
- SMD Plus by Recorder
- 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain, and lighting condition change
- SMD Plus by Camera
- 6 channels
- Audio and Video Access Channel
- 8 channels
- Network Bandwidth
- 80 Mbps incoming, 80 Mbps recording, and 60 Mbps outgoing
- Resolution
- 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF
- Decoding Capability
- AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps
- AI enabled
- 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps
- Video Output
- 1 HDMI, 1 VGA
- HDMI
- 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
- VGA
- 1920 × 1080, 1280 × 1024, 1280 × 720
- HDMI
- 1920 × 1080, 1280 × 1024, 1280 × 720
- VGA
- 1920 × 1080, 1280 × 1024, 1280 × 720
- Multi-screen Display
- Main Screen : 1/4/8/9 views
- Sub Screen
- 1/4/8/9 views
- Third-party Camera Access
- ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha
- Video Compression
- Smart H.265+; H.265; Smart H.264+; H.264
- Audio Compression
- G.711a; G.711u; PCM; G726
- Network Protocol
- HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
- Mobile Phone Access
- iOS; Android
- Interoperability
- ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
- Browsers
- Chrome; IE; Safari; Edge; Firefox
- Multi-channel Playback
- Up to 8 channels
- Record Mode
- General, motion detection; intelligent; alarm
- Backup Method
- USB device and network
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback
- General Alarm
- Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm
- Anomaly Alarm
- Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception
- Intelligent Alarm
- Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
- Alarm Linkage
- Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email
- Audio Input
- 1-channel RCA
- Audio Output
- 1-channel RCA
- Alarm Input
- NA (2 channels is optional)
- Alarm Output
- NA (1-channel 12 V 1 A output is optional)
- HDD Interface
- 1 SATA port. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
- USB
- 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
- HDMI
- 1
- VGA
- 1
- Network Port
- 1 (10/100 Mbps Ethernet port, RJ-45)
- Power Supply
- 12 VDC, 2 A
- Power Consumption
- Total output of NVR is <10 W (without HDD)
- Net Weight
- 0.81 kg (1.79 lb)
- Gross Weight
- 1.38 kg (3.04 lb)
- Product Dimensions
- 260.0 mm × 232.5 mm × 47.6 mm (10.24″ × 9.15″ × 1.87″) (W × D × H)
- Packaging Dimensions
- 334 mm × 89 mm × 314 mm (13.15″ × 3.50″ × 12.36″) (W × D × H)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Storage Temperature
- –20 °C to +60 °C (–4 °F to +140 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Installation
- Rack or desktop
- Certifications
- CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-32:2019+A1:2021; EN 61000-33:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014; CE-LVD: EN 62368-1:2014
- รหัสสินค้า (SKU)
- DHI-NVR4108HS-4KS3
- หมวดหมู่
- เครื่องบันทึก NVR/DVR
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
