- Included Power Adapter
- Yes
- PoE
- Yes
- Ethernet Port
- 24
- Ethernet Port Speed
- 10/100 Mbps
- Optical Port Speed
- 1000 Mbps
- Ethernet Port Uplink Speed
- 10/100/1000 Mbps
- Optical Port Uplink Speed
- 1 Gbps
- Description of Function Slots
- Port 1-24: 24 × RJ-45 10/100 Mbps (PoE); Port 25-26: 2 × RJ-45 10/100/1000 Mbps (combo); Port 25-26: 2 × SFP 1000 Mbps (combo)
- Reset Button
- 1
- Power Supply
- Built-in power supply: 100-240 VDC, 47-63 Hz, max 7 A
- Operating Temperature
- –10 °C to +55 °C (+14 °F to +131 °F)
- Operating Humidity
- 5%–95% (RH), non-condensing
- Storage Temperature
- –40 °C to +70 °C (–40 °F to +158 °F)
- Storage Humidity
- 5%–95% (RH), non-condensing
- Power Consumption
- Idling: ≤8.5 W ; Full load: 400 W
- Layer
- Layer 2
- Management Type
- Yes
- Smart Managed Switch
- Yes
- MTBF
- 64.20 years
- Switching Capacity
- 8.8 Gbps
- Packet Forwarding Rate
- 6.55 Mpps
- Packet Buffer Size
- 4 Mbit
- Jumbo Frame
- 15K Byte
- MAC Table Size
- 8K
- VLAN Number
- 32
- Communication Standard
- IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab; IEEE802.3z
- PoE Protocol
- IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
- PoE Power
- Port 1-2 ≤ 90 W, Port 3-24 ≤ 30 W, total ≤ 375 W
- PoE Power Consumption Management
- Yes
- PoE Pin Assignment
- 1,2,4,5（V+）,3,6,7,8（V-）
- Long Distance PoE Transmission
- Yes
- VLAN Function
- Port-based VLAN
- IEEE 802.3x Flow Control
- Yes
- DHCP Function
- DHCP Client
- Equipment Management
- Web management; App management
- Statics Protection
- Air discharge: 8 kV; Contact discharge: 6 kV
- Lighting Protection
- Common mode: 4 kV; Differential mode: 2 kV
- Net Weight
- 2.62 kg (5.76 lb)
- Gross Weight
- 3.22 kg (7.08 lb)
- Product Dimensions
- 440 mm × 220 mm × 44 mm (17.32″ × 8.66″ × 1.73″) (L × W × H)
- Packaging Dimensions
- 540 mm × 342 mm × 90 mm (21.26″ × 13.46″ × 3.54″) (L × W × H)
- Casing Material
- Sheet metal
- Installation
- Desktop mount; rack mount
