- Included Power Adapter
- Yes
- PoE
- Yes
- Ethernet Port
- 8
- Ethernet Port Speed
- 10/100 Mbps
- Ethernet Port Uplink Speed
- 10/100/1000 Mbps
- Description of Function Slots
- Port 1-8: 8 × RJ-45 10/100 Mbps (PoE); Port 9-10: 2 × RJ-45 10/100/1000 Mbps（uplink）
- Reset Button
- 1
- Power Supply
- External power supply: 54 VDC, 2.22 A
- Operating Temperature
- –10 °C to +55 °C (+14 °F to +131 °F)
- Operating Humidity
- 5%–95% (RH), non-condensing
- Storage Temperature
- –40 °C to +70 °C (–40 °F to +158 °F)
- Storage Humidity
- 5%–95% (RH), non-condensing
- Power Consumption
- Idling: ≤3 W; Full load: 110 W
- Layer
- Layer 2
- Management Type
- Yes
- Smart Managed Switch
- Yes
- MTBF
- 150 years
- Switching Capacity
- 5.6 Gbps
- Packet Forwarding Rate
- 4.17 Mpps
- Packet Buffer Size
- 4 Mbit
- Jumbo Frame
- 9216 Byte
- MAC Table Size
- 8K
- VLAN Number
- 32
- Communication Standard
- IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab
- PoE Protocol
- IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
- PoE Power
- Port 1 ≤ 90 W, Port 2-8 ≤ 30 W, total ≤ 110 W
- PoE Power Consumption Management
- Yes
- PoE Pin Assignment
- 1,2,4,5（V+）,3,6,7,8（V-）
- Long Distance PoE Transmission
- Yes
- VLAN Function
- Port-based VLAN
- IEEE 802.3x Flow Control
- Yes
- DHCP Function
- DHCP Client
- Equipment Management
- Web management; App management
- Statics Protection
- Air discharge: 8 kV; Contact discharge: 6 kV
- Lighting Protection
- Common mode: 4 kV; Differential mode: 2 kV
- Net Weight
- 0.5 kg (1.10 lb)
- Gross Weight
- 1.25 kg (2.76 lb)
- Product Dimensions
- 190 mm × 106 mm × 30 mm (7.48″ × 4.17″ × 1.18″) (L × W × H)
- Packaging Dimensions
- 256 mm × 244 mm × 87 mm (10.07″ × 9.61″ × 3.43″) (L × W × H)
- Casing Material
- Sheet metal
- Installation
- Desktop mount; wall mount
- Certifications
- CE
- รหัสสินค้า (SKU)
- DH-CS4010-8ET-110
- หมวดหมู่
- สวิตช์ PoE สำหรับกล้อง
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
