- Image Sensor
- 1/2.9″ CMOS
- Max. Resolution
- 2560 (H) × 1440 (V)
- ROM
- 128 MB
- RAM
- 128 MB
- Scanning System
- Progressive
- Electronic Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- Min. Illumination
- 0.006 lux@F1.6 (Color,30 IRE)
- 0.0006 lux@F1.6 (B/W,30 IRE)
- 0 lux (Illuminator on)
- S/N Ratio
- > 56 dB
- Illumination Distance
- Up to 30 m (98.43 ft) (IR LED)
- Up to 30 m (98.43 ft) (Warm light)
- Illuminator On/Off Control
- Auto;Manual
- Illuminator Number
- 1 (IR LED); 1 (Warm light)
- Angle Adjustment
- Pan: 0°–360°
- Tilt
- 0°–78°
- Rotation
- 0°–360°
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Focal Length
- 2.8 mm;3.6 mm
- Max. Aperture
- F1.6
- Field of View
- 2.8 mm: H: 94°; V: 52°; D: 111°
- 3.6 mm
- H: 78°; V: 41°; D: 94°
- Iris Control
- Fixed
- Close Focus Distance
- 2.8 mm: 1.1 m (3.61 ft)
- 3.6 mm
- 1.7 m (5.58 ft)
- DORI Distance
- Lens
- Detect
- Observe
- Recognize
- Identify
- 2.8 mm
- 64.0 m
- (209.97 ft) · 25.6 m
- (83.98 ft) · 12.8 m
- (41.99 ft) · 6.4 m
- (21.00 ft)
- 3.6 mm
- 85.4 m
- (280.18 ft) · 34.2 m
- (112.20 ft) · 17.1 m
- (56.10 ft) · 8.5 m
- (27.89 ft)
- Human Detection
- Support the classification and accurate detection of human
- Smart Search
- Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
- Video Compression
- H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
- Smart Codec
- Smart H.265+; Smart H.264+
- Video Frame Rate
- Main stream: 2560 × 1440@(1–25/30 fps)
- Sub stream
- 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
- *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
- Stream Capability
- 2 streams
- Resolution
- 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
- Bit Rate Control
- CBR/VBR
- Video Bit Rate
- H.264: 32 kbps–4096 kbps
- H.265
- 12 kbps–4096 kbps
- Day/Night
- Auto(ICR)/Color/B/W
- BLC
- Yes
- HLC
- Yes
- WDR
- 120 dB
- White Balance
- Auto; natural; street lamp; outdoor; manual; regional custom
- Gain Control
- Auto;Manual
- Noise Reduction
- 3D NR
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Region of Interest (RoI)
- Yes (4 areas)
- Smart Illumination
- Yes
- Image Rotation
- 0°/180°
- Mirror
- Yes
- Privacy Masking
- 4 areas
- Built-in MIC
- Yes, built-in Mic
- Audio Compression
- G.711a; G.711Mu; PCM; G.726
- Alarm Event
- Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception
- Network Port
- RJ-45 (10/100 Base-T)
- SDK and API
- Yes
- Network Protocol
- IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
- Interoperability
- ONVIF (Profile S; Profile T); CGI
- User/Host
- 6 (Total bandwidth: 24 M)
- Storage
- FTP
- Browser
- IE; Chrome; Firefox
- Management Software
- Smart PSS Lite; DSS; DMSS
- Mobile Client
- iOS;Android
- Cyber Security
- Configuration encryption;trusted execution;Digest;security logs;HTTPS;trusted upgrade;WSSE;trusted boot;account lockout;generation and importing of X.509 certification;video encryption
- Certifications
- CE-LVD: EN62368-1
- CE-EMC
- Electromagnetic Compatibility Directive 2014/30/EU
- Power Supply
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 2 W (12 VDC); 2.9 W (PoE)
- Max. (H.265 + intelligence on+ WDR + illuminator intensity)
- 4.6 W (12 VDC); 5.7 W (PoE)
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- ≤95%
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- ≤95%
- Protection
- IP67
- Casing Material
- Inner core: Metal+plastic
- Cover
- Plastic
- Product Dimensions
- 100.9 mm × Φ109.9 mm (3.97″ × Φ4.33″)
- Net Weight
- 0.33 kg (0.73 lb)
- Gross Weight
- 0.45 kg (0.99 lb)
