- Image Sensor
- 1/2.9″ CMOS
- Max. Resolution
- 2688 (H) × 1520 (V)
- ROM
- 128 MB
- RAM
- 128 MB
- Scanning System
- Progressive
- Electronic Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- Min. Illumination
- 0.004 lux@F1.0 (Color, 30 IRE)
- 0.0004 lux@F1.0 (B/W, 30 IRE)
- 0 lux (Illuminator on)
- S/N Ratio
- > 56 dB
- Illumination Distance
- Up to 30 m (98.43 ft) (IR )
- Up to 30 m (98.43 ft) (Warm Light)
- Illuminator On/Off Control
- Auto;Manual
- Illuminator Number
- 2 (IR LED); 2 (Warm light)
- Angle Adjustment
- Pan: 0°–360°
- Tilt
- 0°–90°
- Rotation
- 0°–360°
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Focal Length
- 2.8 mm; 3.6 mm
- Max. Aperture
- F1.0
- Field of View
- 2.8 mm: H: 101.6°; V: 54.8°; D: 122.1°
- 3.6 mm
- H: 84°; V: 45.6°; D: 98.9°
- Iris Control
- Fixed
- Close Focus Distance
- 2.8 mm: 1.4 m (4.59 ft)
- 3.6 mm
- 2.0 m (6.56 ft)
- DORI Distance
- Lens
- Detect
- Observe
- Recognize
- Identify
- 2.8 mm
- 63.8 m (209.32 ft)
- 25.5 m
- (83.66 ft) · 12.8 m
- (41.99 ft) · 6.4 m
- (21.00 ft)
- 3.6 mm
- 77.8 m (255.25 ft)
- 31.1 m
- (102.03 ft) · 15.6 m
- (51.18 ft) · 7.8 m
- (25.59 ft)
- IVS (Perimeter Protection)
- Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- SMD
- SMD Plus
- Smart Search
- Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
- Video Compression
- H.265; H.264; H.264H; H.264B; MJPEG (only supported by sub stream)
- Smart Codec
- Smart H.265+; Smart H.264+
- Video Frame Rate
- Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps);
- sub stream
- 704 × 576@(1–25 fps)/704 × 480@(1–30 fps);
- *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
- Stream Capability
- 2 streams
- Resolution
- 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
- Bit Rate Control
- CBR/VBR
- Video Bit Rate
- H.264: 32 kbps–6144 kbps;
- H.265
- 12 kbps–6144 kbps
- Day/Night
- Auto(ICR)/Color/B/W
- BLC
- Yes
- HLC
- Yes
- WDR
- 120 dB
- White Balance
- Auto; natural; street lamp; outdoor; manual; regional custom
- Gain Control
- Auto/Manual
- Noise Reduction
- 3D NR
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Region of Interest (RoI)
- Yes (4 areas)
- Smart Illumination
- Yes
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
- Mirror
- Yes
- Privacy Masking
- 4 areas
- Built-in MIC
- Yes, built-in Mic
- Built-in Speaker
- Yes, built-in speaker
- Audio Compression
- G.711a; G.711Mu; G.726; PCM
- Alarm Event
- No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception
- Network Port
- RJ-45 (10/100 Base-T)
- SDK and API
- Yes
- Network Protocol
- IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; NFS; P2P; auto registration
- Interoperability
- ONVIF (Profile S; Profile G; Profile T); CGI
- User/Host
- 6 (Total bandwidth: 36 M)
- Storage
- FTP; SFTP; Micro SD card (support max. 256 GB)
- Browser
- IE; Chrome; Firefox
- Management Software
- Smart PSS Lite; DSS; DMSS
- Mobile Client
- iOS;Android
- Cyber Security
- Configuration encryption;Trusted execution;Digest;Security logs;WSSE;Account lockout;syslog;Video encryption;802.1x;IP/MAC filtering;HTTPS;Trusted upgrade;Trusted boot;Generation and importing of X.509 certification
- Certifications
- CE-LVD: EN62368-1;
- CE-EMC
- Electromagnetic Compatibility Directive 2014/30/EU
- Power Supply
- 12 VDC/PoE
- Power Consumption
- Basic: 2.2 W (12 VDC); 3 W (PoE)
- Max. (H.265 + intelligence on + WDR + IR intensity + warm light deterrence + speaker): 11.9 W (12 VDC); 13.6 W (PoE)
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- ≤95%
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- ≤95%
- Protection
- IP67
- Casing Material
- Metal
- Product Dimensions
- 197.9 mm × 80.2 mm × 76.2 mm (7.79″ × 3.16″ × 3.00″) (L × W × H)
- Net Weight
- 0.53 kg (1.17 lb)
- Gross Weight
- 0.67 kg (1.48 lb)
