- Main Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- Operating Interface
- Web, Local GUI
- AI by Recorder
- Face detection, face recognition, perimeter protection, and SMD Plus;
- AI by Camera
- Face detection; face recognition; perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map
- Perimeter Performance AI by Recorder (Number of Channels)
- 2 channels, 10 IVS rules for each channel
- Perimeter Performance of AI by Camera (Number of Channels)
- All channels (8 targets/s)
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- Face Detection Performance of AI by Recorder (Number of Channels): 1 channel (up to 12 face images/s each channel)
- Face Detection Performance of AI by Camera (Number of Channels): All channels (8 targets/s)
- Face Database Capacity
- Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
- Face Recognition Performance of AI by Recorder (Number of Channels): 8-channel FD (by camera) + FR (by recorder),image stream: 12 face images/s, 1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s
- Face Recognition Performance of AI by Camera (Number of Channels): All channels (8 targets/s)
- SMD Plus by Recorder
- 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain, and lighting condition change
- SMD Plus by Camera
- All channels (16 targets/s)
- Access Channel
- 16 channels
- Network Bandwidth
- AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing. AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
- Resolution
- 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF
- Decoding Capability
- AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 4-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps. AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 3-channel 8 MP@30 fps; 3-channel 6 MP@30 fps; 4-channel 5 MP@30 fps; 6-channel 4 MP@30 fps; 12-channel 1080p@30 fps; 16-channel 720p@30 fps
- Video Output
- 1 HDMI, 1 VGA. HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720. VGA: 1920 × 1080, 1280 × 1024, 1280 × 720. *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.
- Multi-screen Display
- 1st Screen: 1/4/8/9/16. 2nd Screen: 1/4/8/9/16
- Third-party Camera Access
- Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon
- Video Compression
- Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
- Audio Compression
- G.711a; G.711u; PCM; G726
- Network Protocol
- HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
- Mobile Phone Access
- iOS; Android
- Interoperability
- ONVIF 22.06(Profile T; Profile S; Profile G); CGI; SDK
- Browser
- Chrome; IE9 and later; Firefox
- Multi-channel Playback
- Up to 16 channels
- Record Mode
- General, motion detection; intelligent; alarm
- Backup Method
- USB device and network
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback
- Disk Group
- Yes
- General Alarm
- Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm
- Anomaly Alarm
- Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception
- Intelligent Alarm
- Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
- Alarm Linkage
- Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email
- Audio Input
- 1-channel RCA
- Audio Output
- 1-channel RCA
- Alarm Input
- 4 channels
- Alarm Output
- 2 channels
- Disk Interface
- 2 SATA ports, up to 16 TB.The maximum HDD capacity varies with environment temperature.
- RS-232
- 1
- USB
- 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
- HDMI
- 1
- VGA
- 1
- Network Port
- 1 (10/100/1000 Mbps Ethernet port, RJ-45)
- PoE Port
- 16 ports, 10/100 Mbps, IEEE 802.3 af/at
- Power Supply
- 100–240 VAC, 47-63 Hz
- Power Consumption
- Total output of NVR is <10 W(without HDD) Total output power of PoE is 130W,the maximum output power of a single port is 25.5W
- Net Weight
- 2.60 kg (5.73 lb)
- Gross Weight
- 3.80 kg (8.38 lb)
- Product Dimensions
- 375.0 mm × 329.3 mm x 53.0 mm (14.76″ × 12.96″ × 2.09″) (W × L × H)
- Packaging Dimensions
- 451.0 mm × 425.0 mm × 147.0 mm (17.75″ × 16.73″ × 5.79″) (W × L × H)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Storage Temperature
- –20 °C to +60 °C (–4 °F to +140 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Installation
- Rack or desktop
- Certifications
- FCC: 47 CFR FCC Part15, SubpartB, Class A; CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014; CE-LVD: EN 62368-1:2014
- รหัสสินค้า (SKU)
- DHI-NVR4216-16P-EI
