- Main Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- Operating Interface
- Web, Local GUI
- AI by Recorder
- Face detection, face recognition, perimeter protection, SMD Plus
- AI by Camera
- Face detection, face recognition, perimeter protection, SMD Plus, people counting, stereo analysis, heat map
- Perimeter Performance of AI by Camera (Number of Channels)
- All channels (8 targets/s)
- Face Attributes
- Gender, age group, glasses, expressions, face mask, beard
- Face Detection Performance of AI by Camera (Number of Channels): All channels (8 targets/s)
- Face Recognition Performance of AI by Camera (Number of Channels): All channels (8 targets/s)
- SMD Plus by Recorder
- 4 channels: Secondary filtering for human and motor vehicles, reducing false alarms caused by leaves, rain, and lighting condition changes
- SMD Plus by Camera
- All channels (16 targets/s)
- Access Channel
- 16 channels
- Network Bandwidth
- AI disabled: 256 Mbps incoming, 256 Mbps recording, and 256 Mbps outgoing. AI enabled: 180 Mbps incoming, 180 Mbps recording, and 180 Mbps outgoing
- Resolution
- 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF
- Decoding Capability
- AI disabled: 2-channel 16 MP@30 fps, 2-channel 12 MP@30 fps, 4-channel 8 MP@30 fps, 4-channel 6 MP@30 fps, 6-channel 5 MP@30 fps, 8-channel 4 MP@30 fps, 16-channel 1080p@30 fps. AI enabled: 1-channel 16 MP@30 fps, 2-channel 12 MP@30 fps, 3-channel 8 MP@30 fps, 3-channel 6 MP@30 fps, 4-channel 5 MP@30 fps, 6-channel 4 MP@30 fps, 12-channel 1080p@30 fps, 16-channel 720p@30 fps
- Video Output
- HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720. VGA: 1920 × 1080, 1280 × 1024, 1280 × 720. Simultaneous: HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720. VGA: 1920 × 1080, 1280 × 1024, 1280 × 720.
- Multi-screen Display
- Main Screen: 1/4/8/9/16. Sub Screen: 1/4/8/9/16
- Third-party Camera Access
- ONVIF, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Hanwha
- Video Compression
- Smart H.265+, H.265, Smart H.264+, H.264
- Audio Compression
- G.711a, G.711u, PCM, G726
- Network Protocol
- HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
- Mobile Phone Access
- iOS, Android
- Interoperability
- ONVIF 22.06 (Profile T, Profile S, Profile G), CGI, SDK
- Browser
- Chrome, IE9 and later, Firefox
- Multi-channel Playback
- Up to 16 channels
- Record Mode
- General, motion detection, intelligent, alarm
- Backup Method
- USB device and network
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback
- Disk Group
- Yes
- General Alarm
- Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
- Anomaly Alarm
- Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, cybersecurity exception
- Intelligent Alarm
- Face detection, face recognition, perimeter protection, SMD Plus, people counting, stereo analysis, heat map
- Alarm Linkage
- Record, snapshot, IPC external alarm output, audio, buzzer, log, preset, email
- Audio Input
- 1-channel RCA
- Audio Output
- 1-channel RCA
- Alarm Input
- 4 channels
- Alarm Output
- 2 channels (1-channel 12V 1A output)
- Disk Interface
- 2 SATA ports, each disk can contain up to 20TB
- USB
- 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
- HDMI
- 1
- VGA
- 1
- Network Port
- 1 (10/100/1000 Mbps Ethernet port, RJ-45)
- Power Supply
- 12 VDC, 4 A
- Power Consumption
- <10W (without HDD)
- Net Weight
- 1.51 kg (3.33 lb)
- Gross Weight
- 2.76 kg (6.08 lb)
- Product Dimensions
- 375 mm × 284.3 mm × 53 mm (14.76″ × 11.19″ × 2.09″) (W × L × H)
- Packaging Dimensions
- 433 mm × 141 mm × 366 mm (17.05″ × 5.55″ × 14.41″) (W × L × H)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Storage Temperature
- –20 °C to +60 °C (–4 °F to +140 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Installation
- Rack or desktop
- Certifications
- CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
- รหัสสินค้า (SKU)
- DHI-NVR4216-EI
- หมวดหมู่
- เครื่องบันทึก NVR/DVR
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
