- Main Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- Operating Interface
- Web, Local GUI
- AI by Recorder
- Face detection; face recognition; perimeter protection; SMD Plus
- AI by Camera
- Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
- AcuPick AI by Camera + Recorder
- Max. 32-channel, 1 combined event per channel/s
- Perimeter Performance AI by Recorder (Number of Channels)
- 4 channels, 10 IVS rules for each channel
- Perimeter Performance of AI by Camera (Number of Channels)
- All channels (16 targets/s)
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- Face Detection Performance of AI by Recorder (Number of Channels): 2 channels (up to 12 face images/s each channel)
- Face Detection Performance of AI by Camera (Number of Channels): 16 channels
- Face Database Capacity
- Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
- Face Recognition Performance of AI by Recorder (Number of Channels): 1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s
- 2. 2-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s
- Face Recognition Performance of AI by Camera (Number of Channels): 16 channels
- SMD Plus by Recorder
- 8 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera
- All channels (32 targets/s)
- Metadata Performance of AI by Camera (Number of Channels)
- 8 channels
- Human Attributes
- Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
- Motor Vehicle Attributes
- License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location.
- Non-motor Vehicle Attributes
- Vehicle model, vehicle color, number of persons, helmet.
- ANPR by Camera (Number of Channels)
- All channels (8 targets/s)
- License Plate Database Capacity
- 1. Create up to 20,000 plate numbers.
- 2. Blocklist and allowlist
- Access Channel
- 32 channels
- Network Bandwidth
- AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing
- AI enabled
- 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
- Resolution
- 32 MP;24 MP;16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF
- Video Output
- 2 VGA, 2 HDMI
- VGA
- 1920 × 1080, 1280 × 1024, 1280 × 720
- HDMI
- 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
- Heterogeneous video source output for HDMI1 and HDMI2
- Simultaneous video source output for VGA1 and HDMI1
- Simultaneous video source output for VGA2 and HDMI2
- Multi-screen Display
- Main screen: 1/4/8/9/16/25/36
- Sub screen
- 1/4/8/9/16
- Video Compression
- Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
- Audio Compression
- G.711a; G.711u; PCM; G726
- Network Protocol
- HTTP; HTTPS; TCP/IP; IPv4; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI
- Mobile Phone Access
- iOS; Android
- Interoperability
- ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK
- Browser
- Chrome; IE; Safari; Edge; Firefox
- Network Mode
- Multi-address mode, load balance, fault tolerance and other network port binding modes
- Multi-channel Playback
- Up to 16 channels
- Record Mode
- General, motion detection; intelligent; alarm; POS
- Backup Method
- USB device and network
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
- Disk Group
- Yes
- RAID
- RAID 0/1/5/6/10
- General Alarm
- Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm
- Anomaly Alarm
- Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception
- Intelligent Alarm
- Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
- Alarm Linkage
- Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email
- Audio Input
- 1-channel RCA
- Audio Output
- 2-channel RCA
- Alarm Input
- 16 channels
- Alarm Output
- 8 channels (1-channel 12 V 1 A output)
- Disk Interface
- 8 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
- eSATA
- 1
- RS-232
- 1
- RS-485
- 2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication)
- USB
- 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
- HDMI
- 2
- VGA
- 2
- Network Port
- 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Power Supply
- 100–240 VAC, 50-60 Hz
- Power Consumption
- Total output of NVR is ≤ 13 W (without HDD)
- Net Weight
- 6.40 kg (14.11 lb)
- Gross Weight
- 9.01 kg (19.86 lb)
- Product Dimensions
- 439.9 mm × 457.9 mm x 89.0 mm (17.32″ × 18.03″ × 3.50″) (W × D × H)
- Packaging Dimensions
- 570.0 mm × 570.0 mm x 226.0 mm (22.44″ × 22.44″ × 8.90″) (W × D × H)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Storage Temperature
- –20 °C to +60 °C (–4 °F to +140 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Installation
- Rack or desktop
- Certifications
- FCC: 47 CFR FCC Part15, SubpartB, Class A
- CE-EMC
- EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
- CE-LVD
- EN 62368-1:2014
