- Processor
- Qualcomm 750MHz CPU, MIPS 74Kc
- Memory
- 128 MB DDR2 RAM, 16 MB Flash
- Interface
- 1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE)
- 1 Reset Button
- Power Supply
- Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
- Voltage range
- 16-27V DC
- Dimensions ( W x D x H )
- 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
- Antenna Gain
- 23 dBi
- Antenna Beamwidth
- 9° (Azimuth)/7° (Elevation)
- Protection
- 15 KV ESD Protection
- 6 KV Lightning Protection
- Enclosure
- Material: Outdoor PC stabilized plastic
- Weatherproof
- IP65 water and dust proof design
- Wireless Standards
- IEEE 802.11a/n/ac
- Wireless Speeds
- Up to 867 Mbps (80 MHz, Dynamic)
- Up to 400 Mbps (40 MHz, Dynamic)
- Up to 173.4 Mbps (20 MHz, Dynamic)
- Frequency
- 5.15–5.85 GHz
- Transmit Power
- Max. 27 dBm (Adjustable power by 1dBm)
- Network Configuration
- WAN: Static/ Dynamic/ PPPoE
- LAN
- Static/ Dynamic/ DHCP
- Forwarding
- ALG/ UPnP/ Virtual Server/ Port Trigger
- Security
- SPI Firewall/ Ping Forbidden/ DoS Protection
- Access Control
- Static Routing
- Bandwidth Control
- IP & MAC Binding
- Management
- Discovery and Remote Management via Pharos Control application
- HTTP/ HTTPS Web-based management
- System log
- SNMP Agent(v2c)
- Ping Watch Dog
- Dynamic DDNS
- SSH Server
- System Tools
- Indicators:Signal Strength/ Noise/ Transmit CCQ/ CPU/ Memory
- Monitors
- Throughput/ Stations/ Interfaces/ ARP/ Routes/ WAN/ DHCP
- Spectrum Analyzer
- Speed Test
- Ping
- Traceroute
- Antenna Alignment
- System-level Optimizations
- Optimized IGMP Snooping / Proxy for multicast applications
- Dimensions(W x D x H)
- 85.8×43.9×29.7 mm
- Interfaces
- 1 AC Jack with Earth Ground
- 1× 10/100/1000 Mbps Shielded Ethernet Port (Power + Data)
- 1× 10/100/1000 Mbps Shielded Ethernet Port (Data)
- Button
- Remote Reset Button
- Power Status LEDs
- Green
- Input
- 100-240VAC, 50/60Hz
- Output
- 24VDC, 0.5A Max
- +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
- Efficiency
- >84.29%
- Certifications
- CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
- Certification
- CE, FCC, RoHS, IP65, IC
- Package Contents
- Outdoor Wireless CPE
- 24V 0.5A Passive PoE Adapter
- Pole Mounting Kits
- AC Power Cord
- Installation Guide
- System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
- Note
- We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
- Environment
- Operating Temperature: -40℃~70℃ (-40℉~158℉)
- Storage Temperature
- -40℃~70℃ (-40℉~158℉)
- Operating Humidity
- 10%~90% non-condensing
- Storage Humidity
- 5%~95% non-condensing
- รหัสสินค้า (SKU)
- TPL-CPE710
