- Presentation
- Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
- Lead time
- Usually in Stock
- Communication port type
- SmartConnect Ethernet port
- SmartSlot
- Software package
- SmartConnect software for remote power monitoring feature availability varies by terms of use
- รันไทม์
- View Runtime Graph
- ประสิทธิภาพ
- View Efficiency Graph
- Battery type
- Lead-acid battery
- Additional information
- Configurable for 220 : 230 or 240 nominal output voltage
- Extended runtime
- 0
- Number of battery filled slots
- 0
- Number of battery free slots
- 0
- Battery recharge time
- 3 h
- Number of battery replacement quantity
- 1
- Battery life
- 3…5 year(s)
- Replacement battery
- APCRBC159
- Battery charger power
- 144 W rated
- Provided equipment
- Installation guide
- Rack mounting support rails
- USB cable
- Number of power module
- 0
- Number of power module filled slots
- 0
- Number of power module free slots
- 0
- product web sub-family
- Cloud-enabled monitoring
- Redundant
- No
- Number of rack unit
- 2U
- Colour
- Black
- Height
- 8.6 cm
- Width
- 43.2 cm
- Depth
- 47.7 cm
- Product weight
- 26.1 kg
- Mounting location
- Front
- Mounting preference
- Lower
- Mounting mode
- Rack-mounted
- Two post mountable
- 0
- USB compatible
- Yes
- Main Input Voltage
- 230 V
- Input Connection Type
- IEC 320 C14
- Input voltage limits
- 151…302 V adjustable
- 160…286 V
- Network frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Main Output Voltage
- 230 V
- Rated power in W
- 1000 W
- Rated power in VA
- 1500 VA
- output connection type
- 4 IEC 320 C13
- 2 IEC Jumpers C13
- Harmonic distortion
- Less than 5 %
- Maximum configurable power in VA
- 1500 VA
- Maximum configurable power in W
- 1000 W
- Transfer time
- 6 ms typical : 10 ms maximum
- UPS type
- Line interactive
- Wave type
- Sine wave
- Output frequency
- 50/60 Hz +/- 3 Hz sync to mains
- Standards
- EN/IEC 62040-1:2019/A11:2021
- EN/IEC 62040-2
- 2006/AC:2006
- EN/IEC 62040-2
- 2018
- Acoustic level
- 46 dBA
- Heat dissipation
- 90 Btu/h
- Operating altitude
- 0…10000 ft
- Ambient air temperature for operation
- 0…40 °C
- Ambient air temperature for storage
- -15…45 °C
- Storage altitude
- 0.0000000000…15240.0000000000 m
- Relative humidity
- 0…95 %
- Storage Relative Humidity
- 0…95 %
- control panel
- Multifunction LCD status and control console
- Emergency power off
- Optional
- Free slots
- 1
- Communication port support
- SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use
- Alarm
- Alarm when on battery : distinctive low battery alarm : configurable delays
- Surge energy rate
- 459 J
- Noise suppression
- Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 25.095 cm
- Package 1 Width
- 59.385 cm
- Package 1 Length
- 60.325 cm
- Package 1 Weight
- 38.240 kg
- Warranty
- 3 years repair or replace (excluding battery) and 2 years for battery
- รหัสสินค้า (SKU)
- SMT1500RMI2UC
- หมวดหมู่
- UPS สำหรับแร็ค
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
