- Interface
- 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
- Button
- Reset
- Power Consumption
- • EU: 12 W
- US
- 13.5 W
- Dimensions ( W x D x H )
- 9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)
- Antenna Type
- Internal Omni
- 2.4 GHz
- 2× 4 dBi
- 5 GHz
- 2× 5 dBi
- Mounting
- Ceiling /Wall Mounting (Kits included)
- Wireless Standards
- IEEE 802.11ax/ac/n/g/b/a
- Frequency
- 2.4 GHz and 5 GHz
- Signal Rate
- 5 GHz: Up to 1201 Mbps
- 2.4 GHz
- Up to 574 Mbps
- Wireless Security
- • Captive Portal Authentication △
- Access Control
- Wireless Mac Address Filtering
- Wireless Isolation Between Clients
- SSID to VLAN Mapping
- Rogue AP Detection
- 802.1X Support
- WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Transmission Power
- • CE:
- <20 dBm(2.4 GHz, EIRP)
- <23 dBm(5 GHz, EIRP)• FCC
- <25 dBm (2.4 GHz)
- <25 dBm (5 GHz)
- Omada App
- Yes
- Centralized Management
- • Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Cloud Access
- Yes (Through OC300, OC200, or Omada Software Controller)
- Email Alerts
- Yes
- LED ON/OFF Control
- Yes
- Management MAC Access Control
- Yes
- SNMP
- v1, v2c, v3
- System Logging Local/Remote Syslog
- Local/Remote Syslog
- SSH
- Yes
- Web-based Management
- HTTP/HTTPS
- L3 Management
- Yes
- Multi-site Management
- Yes
- Management VLAN
- Yes
- Certification
- CE, FCC, RoHS
- Package Contents
- • EAP620 HD
- Power Adapter
- Ceiling/Wall Mounting Kits
- Installation Guide
- System Requirements
- Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
- Environment
- • Operating Temperature: 0–40 ℃ (32–104 ℉)
- Storage Temperature
- -40–70 ℃ (-40–158 ℉)
- Operating Humidity
- 10–90% RH non-condensing
- Storage Humidity
- 5–90% RH non-condensing
