- Interface
- 1× Gigabit Ethernet Port
- Physical Security Lock
- No
- Button
- Reset, LED
- Power Supply
- 100-240 V ~ 50/60 Hz
- Power Consumption
- 18 W
- Dimensions
- 6.3 × 3.1 × 1.5 in (160 × 80 × 37.8 mm)
- Antenna
- 4× External Antennas
- 2.4 GHz
- 2× 3 dBi
- 5 GHz
- 4× 5 dBi
- Mounting
- Plug in
- Coverage
- 140 ㎡ (1500 ft²) ***
- Concurrent Clients
- 250+ **
- Wireless Standards
- IEEE 802.11ax/ac/n/g/b/a
- Frequency
- 2.4 GHz and 5 GHz
- Signal Rate
- • 5 GHz: Up to 4804 Mbps
- 2.4 GHz
- Up to 574 Mbps
- Wireless Security
- • Captive Portal Authentication §
- Access Control
- Wireless Mac Address Filtering
- Wireless Isolation Between Clients
- VLAN
- Rogue AP Detection
- 802.1X Support
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Transmission Power
- • CE:
- <20 dBm (2.4 GHz, EIRP)
- <23 dBm (5 GHz, band1 & band2, EIRP)
- <30 dBm (5 GHz, band3, EIRP)• FCC
- <25 dBm (2.4 GHz)
- <28 dBm (5 GHz)
- Omada App
- Yes
- Centralized Management
- • Omada Hardware Controller
- Omada Software Controller
- Omada Cloud-Based Controller
- Cloud Access
- Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Email Alerts
- Yes
- LED ON/OFF Control
- Yes
- Management MAC Access Control
- Yes
- SNMP
- v1, v2c, v3
- System Logging Local/Remote Syslog
- Yes
- SSH
- Yes
- Web-based Management
- Yes
- Management VLAN
- Yes
- Zero-Touch Provisioning
- Yes. Requiring the use of Omada Cloud-Based Controller.
- Certification
- CE, FCC, IC, RoHS, UL
- Package Contents
- • AX5400 Mesh WiFi 6 Extender EAP673-Extender
- Installation Guide
- Environment
- • Operating Temperature: 0–40 ℃ (32–104 ℉)
- Storage Temperature
- -40–70 ℃ (-40–158 ℉)
- Operating Humidity
- 10–90% RH non-condensing
- Storage Humidity
- 5–90% RH non-condensing
