- Throughput
- Firewall (FW) + Application Visibility and Control (AVC) (1024B): 890 Mbps
- 2.3 Gbps
- 3.3 Gbps
- 5.3 Gbps
- Throughput
- FW + AVC + Intrusion Prevention System (IPS) (1024B): 880 Mbps
- 2.3 Gbps
- 3.3 Gbps
- 4.9 Gbps
- Maximum concurrent sessions, with AVC
- Maximum new connections per second, with AVC
- Transport Layer Security (TLS)
- 195 Mbps
- 850 Mbps
- 1.2 Gbps
- 1.4 Gbps
- Throughput
- NGIPS (1024B): 900 Mbps
- 2.6 Gbps
- 3.5 Gbps
- 6.1 Gbps
- IPSec VPN throughput
- (1024B TCP w/Fastpath)
- 400 Mbps
- 1.2 Gbps
- 1.4 Gbps
- 2.4 Gbps
- Cisco Device Manager (local management)
- Centralized management
- Centralized configuration, logging, monitoring, and reporting are performed by the Threat Defense Manager (FMC) or, alternatively, from the cloud with Cisco Defense Orchestrator
- AVC
- Standard, supporting more than 4000 applications, as well as geolocations, users, and websites
- AVC
- OpenAppID support for custom, open-source application detectors: Standard
- Cisco Security Intelligence
- Standard, with IP, URL, and DNS threat intelligence
- Cisco IPS
- Available; can passively detect endpoints and infrastructure for threat correlation and Indicators of Compromise (IoC) intelligence
- Cisco Malware Defense for Networks
- Available; enables detection, blocking, tracking, analysis, and containment of targeted and persistent malware, addressing the attack continuum both during and after attacks.
- Integrated threat correlation with Cisco AMP for Endpoints is also optionally available
- Cisco Malware Analytics sandboxing
- Available
- URL filtering
- number of categories: More than 80
- URL filtering
- number of URLs categorized: More than 280 million
- Automated threat feed and IPS signature updates
- Yes: class-leading Collective Security Intelligence (CSI) from the Cisco Talos ® group (https://www.cisco.com/c/en/us/products/security/talos.html)
- Third-party and open- source ecosystem
- Open API for integrations with third-party products; Snort ® and OpenAppID community resources for new and specific threats
- High availability and clustering
- Active/standby
- Cisco Trust Anchor Technologies
- Cisco Firepower 1000 Series platforms include Trust Anchor Technologies for supply chain and software image assurance. Please see the section below for additional details
- Features
- 1010
- 1010E
- 1120
- 1140
- 1150
- Dimensions
- (H x W x D)
- 1.82 x 7.85 x 8.07 in.
- 1.72 x 17.2 x 10.58 in.
- 1.72 x 17.2 x 10.58 in.
- 1.72 x 17.2 x 10.58 in.
- Form factor
- Compact (Desktop, wall-mount)
- Rack mount, 1U
- Rack mount, 1U
- Rack mount, 1U
- Network interfaces
- 8 x 1000BASE-T
- 8 x 1000BASE-T
- 4 x SFP · 8 x RJ-45
- 4 x SFP · 8 x RJ-45
- 2 x SFP
- 2 x SFP+
- Power over Ethernet
- 2 ports PoE+ (IEEE 802.3at)
- N/A
- N/A
- N/A
- N/A
- Management interfaces
- 1x 1000BASE-T
- 1x Serial console (RJ-45) · 1x 1000BASE-T
- 1x Serial console (RJ-45) · 1x 1000BASE-T
- 1x Serial console (RJ-45) · 1x 1000BASE-T
- 1x Serial console (RJ-45)
- USB
- 1 x USB 3.0 Type-A (500mA)
- 1 x USB 3.0 Type-A (500mA)
- 1 x USB 3.0 Type-A (500mA)
- 1 x USB 3.0 Type-A (500mA)
- Storage
- 1 x 200 GB
- 1 x 200 GB
- 1 x 200 GB
- 1 x 200 GB
- Power supply configuration
- External power supply, AC input
- Integrated, single AC input
- Integrated, single AC input
- Integrated, single AC input
- AC input voltage
- 100 to 240V AC
- 100 to 240V AC
- 100 to 240V AC
- 100 to 240V AC
- AC maximum current draw
- < 2A at 100V, < 1A at 240V
- < 2A at 100V, < 1A at 240V
- < 2A at 100V, < 1A at 240V
- < 2A at 100V, < 1A at 240V
- AC frequency
- 50 to 60 Hz
- 50 to 60 Hz
- 50 to 60 Hz
- 50 to 60 Hz
- AC efficiency
- >88% at 50% load
- >85% at 50% load
- >85% at 50% load
- >85% at 50% load
- Fans
- None
- 1 integrated fan
- 1 integrated fan
- 1 integrated fan
- Noise
- 0 dBA
- 31.7 dBA @ 25C, 56.8 dBA at highest system performance
- 34.2 dBA @ 25C, 56.8 dBA at highest system performance
- 34.2 dBA @ 25C, 56.8 dBA at highest system performance
- Rack mounting
- Via optional rack mount kit
- 2-post mounting Brackets included.
- 2-post mounting Brackets included.
- 2-post mounting Brackets included.
- Weight
- 3 lb (1.4 kg)
- 8 lb (3.6 kg)
- 8 lb (3.6 kg)
- 8 lb (3.6 kg)
- Temperature
- operating: 32 to 104°F
- (0 to 40°C) · 32 to 104°F
- (0 to 40°C) · 32 to 104°F
- (0 to 40°C) · 32 to 104°F
- (0 to 40°C)
- Temperature
- nonoperating: -13 to 158°F (-25 to 70°C)
- -13 to 158°F
- (-25 to 70°C) · -13 to 158°F
- (-25 to 70°C) · -13 to 158°F
- (-25 to 70°C)
- Humidity
- operating: 90% noncondensing
- 90% noncondensing
- 90% noncondensing
- 90% noncondensing
- Humidity
- nonoperating: 10 to 90%
- noncondensing · 10 to 90% noncondensing · 10 to 90% noncondensing · 10 to 90% noncondensing
- Altitude
- operating: 9,843 ft (max)
- 3,000 m (max) · 9,843 ft (max)
- 3,000 m (max) · 9,843 ft (max)
- 3,000 m (max) · 9,843 ft (max)
- 3,000 m (max)
- Altitude
- nonoperating: 15,000 ft (max)
- 15,000 ft (max)
- 15,000 ft (max)
- 15,000 ft (max)
