- Image Sensor
- 1/2.8″ CMOS
- Max. Resolution
- 1920 (H) × 1080 (V)
- ROM
- 128 MB
- RAM
- 512 MB
- Scanning System
- Progressive
- Electronic Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- Min. Illumination
- 0.002 lux@F1.6 (Color, 30 IRE)
- 0.0002 lux@F1.6 (B/W, 30 IRE)
- 0 lux (Illuminator on)
- S/N Ratio
- >56 dB
- Illumination Distance
- 50 m (164.04 ft) (IR)
- Illuminator On/Off Control
- Auto; manual
- Illuminator Number
- 1 (IR LED)
- Pan/Tilt/Rotation Range
- Pan: 0°–360°
- Tilt
- 0°–78°
- Rotation
- 0°–360°
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Focal Length
- 2.8 mm; 3.6 mm; 6 mm
- Max. Aperture
- F1.6
- Field of View
- 2.8 mm: Horizontal: 106°; Vertical: 57°; Diagonal: 126°
- 3.6 mm
- Horizontal: 87°; Vertical: 46°; Diagonal: 104°
- 6 mm
- Horizontal: 53°; Vertical: 30°; Diagonal: 60°
- Iris Control
- Fixed
- Close Focus Distance
- 2.8 mm: 0.6 m (1.97 ft)
- 3.6 mm
- 1.2 m (3.94 ft)
- 6 mm
- 2.5 m (8.20 ft)
- DORI Distance
- Lens
- Detect
- Observe
- Recognize
- Identify
- 2.8 mm
- 38.6 m (126.64 ft)
- 15.4 m (50.52 ft)
- 7.7 m
- (25.26 ft) · 3.9 m
- (12.80 ft)
- 3.6 mm
- 55.2 m (181.10 ft)
- 22.1 m (72.51 ft)
- 11.0 m (36.09 ft)
- 5.5 m
- (18.04 ft)
- 6 mm
- 82.8 m (271.65 ft)
- 33.1 m (108.60 ft)
- 16.6 m (54.46 ft)
- 8.3 m
- (27.23 ft)
- IVS
- Abandoned object; missing object
- Heat Map
- Yes
- IVS (Perimeter Protection)
- Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
- SMD 3.0
- Less false alarm, longer detection distance
- Face Detection
- Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face snapshot set as face, one-inch photo or custom; 3 snapshot strategies (real-time snapshot, optimization snapshot and quality first); face angle filter; optimization time setting
- People Counting
- Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.
- Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
- Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.
- Smart Search
- Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
- Video Compression
- H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
- Smart Codec
- Smart H.265+; Smart H.264+
- AI Coding
- AI H.265; AI H.264
- Video Frame Rate
- Main stream: 1080p@(1–25/30 fps)
- Sub stream
- D1@(1–25/30 fps)
- Third stream
- 1080p@(1–25/30 fps)
- *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
- Stream Capability
- 3 streams
- Resolution
- 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
- Bit Rate Control
- CBR/VBR
- Video Bit Rate
- H.264: 3 kbps–20480 kbps
- H.265
- 3 kbps–20480 kbps
- Day/Night
- Auto(ICR)/Color/B/W
- BLC
- Yes
- HLC
- Yes
- WDR
- 120 dB
- Scene Self-adaptation (SSA)
- Yes
- White Balance
- Auto; natural; street lamp; outdoor; manual; regional custom
- Gain Control
- Auto; manual
- Noise Reduction
- 3D NR
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Region of Interest (RoI)
- Yes (4 areas)
- Defog
- Yes
- Image Rotation
- 0°/90°/180°/270°
- Mirror
- Yes
- Privacy Masking
- 8 areas
- Audio Compression
- PCM; G.711a; G.711Mu; G.726; G.723
- Network Port
- RJ-45 (10/100 Base-T)
- SDK and API
- Yes
- Cyber Security
- Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
- Network Protocol
- IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
- Interoperability
- ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P
- User/Host
- 20 (Total bandwidth: 80 M)
- Storage
- FTP; SFTP; Micro SD card (support max. 256 GB); NAS
- Browser
- IE: IE 8 and later
- Chrome
- Firefox
- Management Software
- Smart PSS; DSS; DMSS
- Mobile Client
- iOS; Android
- Certifications
- CE-LVD: EN60950-1
- CE-EMC
- Electromagnetic Compatibility Directive 2014/30/EU
- FCC
- 47 CFR FCC Part 15, Subpart B
- UL/CUL
- UL60950-1
- CAN/CSA C22.2 No.60950-1-07
- Audio Input
- 1 channel (RCA port)
- Audio Output
- 1 channel (RCA port)
- Alarm Input
- 1 channel in: 5 mA 3–5 VDC
- Alarm Output
- 1 channel out: 300 mA 12 VDC
- Power Supply
- 12 VDC/PoE (802.3af)/ePoE
- Power Consumption
- Basic: 2.3 W (12 VDC); 2.8 W (PoE)
- Max. (H.265 + three streams + intelligence on + IR on )
- 4.8 W (12 VDC); 5.5 W (PoE)
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- ≤95%
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Protection
- IP67; IK10
- Casing
- Metal + plastic
- Product Dimensions
- Φ122 mm × 88.9 mm (4.80″ × Φ3.50″)
- Net Weight
- 455 g (1.00 lb)
- Gross Weight
- 615 g (1.36 lb)
