- GE RJ45 WAN / DMZ Ports
- 1
- GE RJ45 Internal Ports
- 3
- GE RJ45 FortiLink Ports
- 1
- GE RJ45 PoE/+ Ports
- –
- Wireless Interface
- –
- USB Ports
- 1
- Console (RJ45)
- 1
- Internal Storage
- –
- IPS Throughput
- 1 Gbps
- NGFW Throughput
- 800 Mbps
- Threat Protection Throughput
- 600 Mbps
- Firewall Throughput (1518 / 512 / 64 byte UDP packets)
- 5/5/5 Gbps
- Firewall Latency (64 byte UDP packets)
- 4 μs
- Firewall Throughput (Packets Per Second)
- 7.5 Mpps
- Concurrent Sessions (TCP)
- 700,000
- New Sessions/Second (TCP)
- 35,000
- Firewall Policies
- 5,000
- IPsec VPN Throughput (512 byte)
- 4.4 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels
- 200
- Client-to-Gateway IPsec VPN Tunnels
- 250
- SSL-VPN Throughput
- 490 Mbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)
- 200
- SSL Inspection Throughput (IPS, avg. HTTPS)
- 310 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS)
- 320
- SSL Inspection Concurrent Session (IPS, avg. HTTPS)
- 55,000
- Application Control Throughput (HTTP 64K)
- 990 Mbps
- CAPWAP Throughput (HTTP 64K)
- 3.5 Gbps
- Virtual Domains (Default / Maximum)
- 10 / 10
- Maximum Number of FortiSwitches Supported
- 8
- Maximum Number of FortiAPs (Total / Tunnel Mode)
- 10 / 5
- Maximum Number of FortiTokens
- 500
- Maximum Number of Registered FortiClients
- 200
- High Availability Configurations
- Active / Active, Active / Passive, Clustering
- Height x Width x Length (inches)
- 1.44 x 5.5 x 8.52
- Height x Width x Length (mm)
- 36.5 x 140 x 216
- Weight
- TBA
- Form Factor
- Desktop
- Power Required
- 100–240V AC, 60–50 Hz (External DC Power Adapter, 12 VDC)
- Maximum Current
- 100V AC / 0.2A, 240V AC / 0.1A
- Total Available PoE Power Budget
- N/A
- Power Consumption (Average / Maximum)
- 12.4 W / 15.4 W
- Heat Dissipation
- 52.55 BTU/hr
- Operating Temperature
- 32–104°F (0–40°C)
- Storage Temperature
- -31–158°F (-35–70°C)
- Humidity
- 10–90% non-condensing
- Noise Level
- Fanless 0 dBA
- Operating Altitude
- Up to 7,400 ft (2,250 m)
- Compliance
- FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB
- Certifications
- ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
- รหัสสินค้า (SKU)
- ITX-FORTIGATE-40F-01
- หมวดหมู่
- ไฟร์วอลล์ & โหลดบาลานซ์
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
