- 10/5/2.5/GE RJ45 or 10GE/GE SFP+/ SFP Shared Media pairs
- 2
- GE RJ45 Internal Ports
- 8
- Wireless Interface
- –
- USB Ports
- 1
- Console (RJ45)
- 1
- Internal Storage
- 1 x 120 GB SSD
- Trusted Platform Module (TPM)
- Yes
- Bluetooth Low Energy (BLE)
- Yes
- IPS Throughput
- 4.5 Gbps
- NGFW Throughput
- 2.5 Gbps
- Threat Protection Throughput
- 2.2 Gbps
- Firewall Throughput (1518 / 512 / 64 byte UDP packets)
- 28 / 28 / 27.9 Gbps
- Firewall Latency (64 byte UDP packets)
- 3.23 μs
- Firewall Throughput (Packets Per Second)
- 41.85 Mpps
- Concurrent Sessions (TCP)
- 3 M
- New Sessions/Second (TCP)
- 124,000
- Firewall Policies
- 5,000
- IPsec VPN Throughput (512 byte)
- 25 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels
- 200
- Client-to-Gateway IPsec VPN Tunnels
- 2,500
- SSL-VPN Throughput
- 1.4 Gbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)
- 200
- SSL Inspection Throughput (IPS, avg. HTTPS)
- 2.6 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS)
- 1,400
- SSL Inspection Concurrent Session (IPS, avg. HTTPS)
- 300,000
- Application Control Throughput (HTTP 64K)
- 6.7 Gbps
- CAPWAP Throughput (HTTP 64K)
- 23.6 Gbps
- Virtual Domains (Default / Maximum)
- 10 / 10
- Maximum Number of FortiSwitches Supported
- 24
- Maximum Number of FortiAPs (Total / Tunnel Mode)
- 128 / 64
- Maximum Number of FortiTokens
- 500
- High Availability Configurations
- Active-Active, Active-Passive, Clustering
- Height x Width x Length (inches)
- 1.65 x 8.5 x 7.0
- Height x Width x Length (mm)
- 42 x 216 x 178
- Weight
- 2.47 lbs (1.12 kg)
- Form Factor
- Desktop
- Input Rating
- 12V DC, 3A (dual redundancy optional)
- Power Required (Redundancy Optional)
- Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
- Power Supply Efficiency Rating
- 80Plus Compliant
- Maximum Current
- 115Vac/0.4A, 230Vac/0.2A
- Power Consumption (Average / Maximum)
- 22.4 W / 23.5 W
- Heat Dissipation
- 80.1 BTU/hr
- Operating Temperature
- 32°F to 104°F (0°C to 40°C)
- Storage Temperature
- -31°F to 158°F (-35°C to 70°C)
- Humidity
- 10% to 90% non-condensing
- Noise Level
- 21.73 dBA
- Operating Altitude
- Up to 10,000 ft (3,048 m)
- Compliance
- FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
- Certifications
- USGv6/IPv6
