- Radio/Range
- 2.4GHz Bluetooth radio v4.2 with Adaptive Frequency Hopping. Class 1: 100 m line of sight (default), programmable to Class 2: 10 m line of sight
- Battery
- 2400 mAh Li-ion minimum
- Number of Scans
- Up to 65,000 scans per charge
- Expected Duration of Operation
- 18 hours
- Expected Charge Time
- 4.5 hours
- User Indicators
- Good Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume), Vibration (adjustable), Charge Status Indicator
- Dimensions (L x W x H)
- Scanner: 104.1 mm x 71.1 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
- Presentation Base
- 132 mm x 101 mm x 81 mm (5.2 in x 4.0 in x 3.2 in)
- Desktop/Wall Mount Base
- 231 mm x 89 mm x 83 mm (9.1 in x 3.5 in x 3.3 in)
- Weight
- Scanner: 212.62 g (7.5 oz)
- Presentation Base
- 179 g (6.3 oz)
- Desktop/Wall Mount Base
- 260 g (9.2 oz)
- Operating Power (Charging) Bases
- 2.5 W (500 mA @ 5V DC)
- Non-Charging Power (Bases)
- 0.75 W (150 mA @ 5V DC)
- Host System Interfaces
- USB, Keyboard Wedge, RS-232, IBM 46xx (RS485)
- Operating Temperature
- Scanner: 0°C to 50°C (32°F to 122°F)
- Bases Charging
- 5°C to 40°C (41°F to 104°F), Non-Charging: 0°C to 50°C (32°F to 122°F)
- Storage Temperature
- -40°C to 70°C (-40°F to 158°F)
- Electrostatic Discharge (ESD)
- ±8 kV indirect coupling plane, ±15 kV direct air
- Humidity
- 0 to 95% relative humidity, non-condensing
- Tumble Spec
- 2,000 0.5 m (1.6 ft) tumbles (impacts)
- Drop
- Engineered to withstand 50 1.8 m (6 ft) drops to concrete
- Environmental Sealing (Scanner)
- IP52
- Light Levels
- 0 to 100,000 lux (9,290 foot-candles)
- Scan Pattern
- Area Image (1280 x 800 pixel array)
- Motion Tolerance
- Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus
- Scan Angle
- SR: Horizontal: 42° ; Vertical: 27°
- HD
- Horizontal: 42° ; Vertical: 27°
- UD
- Horizontal: 40° ; Vertical: 26°
- Print Contrast
- 20% minimum reflectance difference
- Roll, Pitch, Skew
- ±360°, ±45°, ±65°
- Decode Capabilities
- Reads standard 1D, PDF, 2D, Postal, Digimarc, DOT Code, and OCR symbologies
- (Note
- Decode capabilities dependent on configuration.)
- *Xenon XP 1952g UV
- Built to detect UV watermarks embedded in 1D and 2D barcodes
- Warranty
- Three-year factory warranty
- รหัสสินค้า (SKU)
- 1952GSR-2USB-5-A
- หมวดหมู่
- เครื่องอ่านบาร์โค้ด
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
