- Category
- Specifications
- Antenna
- Internal Antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)
- Power
- Power over Ethernet: 37 – 57 V (802.3af compatible)
- Alternative
- 12 V DC input
- Power consumption
- 15W max (802.3af). Note: actual power consumption may vary depending on the AP usage.
- Power over Ethernet injector and DC adapter sold separately
- Note
- Actual power consumption may vary depending on the AP usage.
- Interfaces
- 1x 10/100/1000 BASE-T Ethernet (RJ45)
- 1x DC power connector (5.5 mm x 2.5 mm, center positive)
- Mounting
- All standard mounting hardware included
- Desktop, ceiling, and wall mount capable
- Ceiling tile rail (9/16, 15/16 or 1 1⁄2” flush or recessed rails), assorted cable junction boxes
- Bubble level on mounting cradle for accurate horizontal wall mounting
- Physical Security
- Two security screw options (included) (10 mm long and 2.5 mm diameter and 4.7 mm head)
- Kensington lock hard point
- Concealed mount plate with anti-tamper cable bay
- Environment
- Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
- Humidity
- 5 to 95% non-condensing
- Operating altitude
- Up to 40,000 feet (12,192 meters)
- Reliability
- Mean Time Between Failure (MTBF): 257,215hrs at +25°C operating temperature
- Physical Dimensions
- 9.84” x 4.72” x 1.42” (25 cm x 12 cm x 3.6 cm), not including desk mount feet or mount plate
- Weight
- 17.35 oz (492 g)
- Quality of Service
- Advanced Power Save (U-APSD)
- WMM Access Categories with DSCP and 802.1p support
- Layer 7 application traffic identification and shaping
- Mobility
- PMK, OKC, & 802.11r for fast Layer 2 roaming
- Distributed or centralized layer 3 roaming
- Analytics
- Embedded location analytics reporting and device tracking
- Global L7 traffic analytics reporting per network, per device, & per application
- LED Indicators
- 1 power/booting/firmware upgrade status
- Regulatory
- RoHS
- For additional country-specific regulatory information, please contact Meraki sales
- รหัสสินค้า (SKU)
- MR36-HW
- หมวดหมู่
- แอคเซสพอยต์ & Wi-Fi
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
