- CPU
- Marvell OCTEON TX2™ CN9130 / CN9131 ARMv8 Cortex-A72 4-core 2.2GHz processor
- CPU Architecture
- 64-bit ARM
- System Memory
- 4 GB SODIMM DDR4 (1 x 4GB)
- Maximum Memory
- 32 GB (1 x 32 GB)
- Memory Slot
- 1 x SODIMM DDR4
- QTS Firmware version 5.0.1(0426) and later will support ECC.
- Flash Memory
- 4GB (Dual boot OS protection)
- Drive Bay
- 4 x 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive Compatibility
- 3.5-inch bays:
- 3.5-inch SATA hard disk drives
- 2.5-inch SATA solid state drives
- M.2 Slot
- 2 x M.2 2280 PCIe Gen 3 x1 slots
- Compatible with NVMe SSD PCIe Gen 3 and above. Please refer to https://www.qnap.com/compatibility/ for compatibility.
- 2.5 Gigabit Ethernet Port (2.5G/1G/100M)
- 2 (2.5G/1G/100M)
- 10 Gigabit Ethernet Port
- 2 x 10GbE SFP+
- USB 2.0 port
- 2
- USB 3.2 Gen 1 port
- 2
- Form Factor
- 1U Short Depth Rackmount
- LED Indicators
- HDD 1-4, Status, LAN, USB, M.2 SSD 1-2
- Buttons
- Power, Reset
- Dimensions (HxWxD)
- 43.3 × 430 × 292.12 mm
- Excludes ear hook and the protruding part of the Power Supply Unit.
- Weight (Net)
- 4.91 kg
- Weight (Gross)
- 5.82 kg
- Operating Temperature
- 0 – 40 °C (32°F – 104°F)
- Storage Temperature
- -20 – 70°C (-4°F – 158°F)
- Relative Humidity
- 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
- Power Supply Unit
- 100W PSU, 100-240V
- Power Consumption
- HDD Sleep Mode: 17.367 W
- Power Consumption
- Operating Mode, Typical: 30.878 W
- Fan
- 3 x 40mm, 12VDC
- System Warning
- Buzzer
- Standard Warranty
- 3 years
- Max. Number of Concurrent Connections (CIFS) – with Max. Memory: 1500
- รหัสสินค้า (SKU)
- TS-435XEU-4G
- หมวดหมู่
- อุปกรณ์ NAS
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
