- Interface
- 1× 2.5G Ethernet Port
- Button
- Reset
- Power Supply
- 802.3at PoE or 12V/1.5A DC (Power Adapter Is Not Included)
- Power Consumption
- 17.83 W (For PoE)
- 13.99 W (For DC)
- Dimensions ( W x D x H )
- 6.3 × 6.3 × 1.4 in (160 × 160 × 36.7 mm)
- Antenna Type
- 2.4 GHz: 2× 4.0 dBi
- 5 GHz: 2× 5.0 dBi
- Mounting
- Ceiling / Wall Mounting (Kits Included)
- Coverage
- 140㎡(1500 ft²) ***
- Wireless Client Capacity
- 250+ **
- Wireless Standards
- IEEE 802.11 a/b/g/n/ac/ax/be
- Frequency
- 2.4 GHz and 5 GHz
- Signal Rate
- 688 Mbps (2.4 GHz) + 4324 Mbps (5 GHz)
- Wireless Functions
- 4K-QAM ‡
- Seamless Roaming
- MU-MIMO ‡
- EHT240 ‡
- Mesh △
- OFDMA ‡
- Load Balance
- Band Steering
- Beamforming
- Airtime Fairness
- Multiple SSIDS:16(8 on each band)
- Wireless Schedule
- Reboot Schedule
- QoS(WMM)
- Rate Limit
- Static IP/Dynamic IP
- RADIUS Accounting
- MAC Authentication
- Wireless Security
- Captive Portal Authentication △
- Access Control
- Maximum number of MAC Filter: 4,000
- Wireless Isolation Between Clients
- VLAN
- Rogue AP Detection
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Transmission Power
- < 25 dBm (2.4GHz)
- < 25 dBm (5GHz, band 1&band 4)
- < 24 dBm (5GHz, band 2&band 3)
- Omada App
- Yes
- Centralized Management
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
- Cloud Access
- Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
- Email Alerts
- Yes
- LED ON/OFF Control
- Yes
- Management MAC Access Control
- Yes
- SNMP
- v1, v2c, v3
- System Logging Local/Remote Syslog
- Yes
- Web-based Management
- Yes
- Certification
- CE, FCC, RoHS, IC
- Package Contents
- EAP723
- Installation Guide
- Ceiling/Wall Mounting Kit
- Environment
- Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
- Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
- Operating Humidity: 10%–90% non-condensing;
- Storage Humidity: 5%–90% non-condensing;
