- Interface
- • 6× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3af PoE and 802.3at PoE+)
- Auto-Negotiation/Auto MDI/MDIX
- Fan Quantity
- Fanless
- Physical Security Lock
- √
- Power Supply
- DC Power Adapter (Output: 53.5VDC / 1.31A)
- PoE Ports (RJ45)
- • Standard: 802.3af PoE and 802.3at PoE+ compliant
- PoE Ports
- 4 ports
- PoE Budget
- 65W available for all PoE+ ports, 30W max per port
- Fast PoE & Perpetual PoE
- PoE Auto Recovery ‡
- Up to 250m PoE transmission distance**
- Dimensions ( W x D x H )
- 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
- Surge Protection
- ±6kV
- Switching Capacity
- 12 Gbps
- Packet Forwarding Rate
- 7.4 Mpps
- MAC Address Table
- 8K
- Packet Buffer Memory
- 4 Mbit
- Jumbo Frame
- 15 KB
- Quality of Service
- • Port-based/802.1p/DSCP QoS
- 8 Priority Queues
- Priority Schedule Mode
- WRR (Weighted Round Robin)
- Queue Weight Config
- Bandwidth Control
- Port-Based Rating Limit
- Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control △
- L2 Features
- • Static Link Aggregation
- Loop Prevention / Loopback Detection
- Flow Control
- 802.3x Flow Control
- Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
- Port Statistics
- Port Mirror Status
- Traffic Statistics
- 802.1ab LLDP
- L2 Multicast
- • IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
- VLAN
- • MTU VLAN
- Port-Based VLAN
- 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID
- Transmission Method
- Store-And-Forward
- Omada App
- Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Centralized Management
- • Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
- Cloud Access
- Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Zero-Touch Provisioning
- Yes. Requires the use of Omada Cloud-Based Controller
- Management Features
- • Web-based GUI
- DHCP Client
- Cable Diagnostics
- Automatic Device Discovery †
- Batch Configuration †
- Batch Firmware Upgrading †
- Unified Configuration †
- Certification
- FCC, CE, RoHS
- Package Contents
- • ES206GP
- Power Adapter
- Power Cord
- Rubber Feet
- Installation Guide
- Environment
- • Operating Temperature: -5℃~40℃ (23℉~104℉)
- Storage Temperature
- -40℃~70℃ (-40℉~158℉)
- Operating Humidity
- 10%~90% non-condensing
- Storage Humidity
- 5%~90% non-condensing
- รหัสสินค้า (SKU)
- ES206GP
- หมวดหมู่
- สวิตช์
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
