Name: TP-Link InSight S225 VIGI 2MP Full-Color Dome Network Camera
Brand: TP-Link

รายละเอียดสินค้า

รุ่น	InSight S225
Type	Fixed Focal Lens
Web Browser	• Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and above
Audio Input	Yes (Built-in Microphone)
On-board Storage	N/A
Storage Temperature	-40 °C to 60 °C (-40 °F to 140 °F)
Storage Humidity	95% or Less (Non-Condensing)
Wide Dynamic Range	DWDR
Client	VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Audio Communication	N/A
Audio Output	N/A
Audio Compression	Yes
Audio Sampling Rate	8 KHz
Audio Bit Rate	64 Kbps(G.711 alaw)
Built-in Microphone	Yes; Records Anything Going on within a 15 ft (4.6 m) Radius of the Camera
Built-in Speaker	N/A
Audio	N/A
กำลังไฟ	DC Power Port
เลนส์ที่จำหน่าย	2.8 มม. / 4 มม.
เซนเซอร์ภาพ	1/3” Progressive Scan CMOS
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/ Scheduled/ Auto
FOV	• 2.8 mm:Horizontal FOV: 98.8°, Vertical FOV: 53.5°, Diagonal FOV: 117°• 4 mm:Horizontal : 75.2°, Vertical: 40.8°, Diagonal: 88.3°
Lens Mount	M12
DORI Distance	• 2.8 mmDetect: 154.2 ft (47 m)Observe: 62.3 ft (19 m)Recognize: 29.5 ft (9 m)Identify: 16.4 ft (5 m)• 4 mmDetect: 193.6 ft (59 m)Observe: 82 ft (25 m)Recognize: 39.4 ft (12 m)Identify: 19.7 ft (6 m)
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
ความละเอียดสูงสุด	1920x1080
Main Stream	• Frame Rate：50Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:1920x1080, 1280x960, 1280x720• Note: If the image rotation is set to 90°, the frame rate only supports up to 20fps.
Sub-Stream	• Frame Rate：50Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:848x480,704x576, 640x480, 640x360,352x288, 320x240• Note: If the image rotation is set to 90°, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Bit Rate	• Main Stream: 256 Kbps to 4 Mbps• Sub-Stream: 64 Kbps to 512 Kbps
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Alarm Linkage	• Upload to FTP server• Push Notifications• Send to Alarm Server• Email Alarm
Alarm	N/A
Reset Button	N/A
Protection	IP67 Waterproof, IK10 Vandal Proof
Environment Noise Filtering	Yes
Operating Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
Operating Humidity	95% or Less (Non-Condensing)
อุปกรณ์ในกล่อง	• VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
Material	Metal
Net Weight	0.5 Kg
Product Dimensions (L x W x H)	Ø4.5 × 3.4 in (Ø113.5 × 85.7mm)
Certifications	CE, NTRA, KC, FCC, VCCI, BSMI, ONVIF, IP67, IK10
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	0.005 Lux; 0 Lux with IR/White light
ระยะโฟกัส	2.8 มม. / 4 มม.
Aperture	F2.0
ช่วงปรับมุม	Pan: 0° to 353.5°, Tilt: 0° to 75°, Rotate: 0° to 355°
Integrated Infrared-White LED	• Quantity: 2• IR Range: 98 ft (30 m)3• White LED Range: 98 ft (30 m)3• IR Wavelength: 850 nm
การบีบอัดวิดีโอ	• Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264
H.264 Type	High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Image Settings	• Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance• Prevent Overexposure to Infrared Light• HLC Adjustable by Client Software
Image Enhancement	BLC/3D DNR/HLC/Smart IR
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
ONVIF	Yes
API	Open Network Video Interface (Profile S/T)
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Cloud	Yes
Smart Event	• Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• People Detection• Vehicle Detection
Basic Event	• Motion detection(Enhanced with Human & Vehicle Classification for more accurate alerts)• Camera Tampering• Exception (Illegal Login)
แหล่งจ่ายไฟ	• 12V DC ± 5%, Max. 6.3 W, 5.5 mm Coaxial Power Plug• PoE: 802.3af/at, class 0, Max. 6.7 W
ระยะเวลารับประกัน	3 ปี

รายละเอียดสินค้า

รุ่น	InSight S225
Type	Fixed Focal Lens
Web Browser	• Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and above
Audio Input	Yes (Built-in Microphone)
On-board Storage	N/A
Storage Temperature	-40 °C to 60 °C (-40 °F to 140 °F)
Storage Humidity	95% or Less (Non-Condensing)
Wide Dynamic Range	DWDR
Client	VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Audio Communication	N/A
Audio Output	N/A
Audio Compression	Yes
Audio Sampling Rate	8 KHz
Audio Bit Rate	64 Kbps(G.711 alaw)
Built-in Microphone	Yes; Records Anything Going on within a 15 ft (4.6 m) Radius of the Camera
Built-in Speaker	N/A
Audio	N/A
กำลังไฟ	DC Power Port
เลนส์ที่จำหน่าย	2.8 มม. / 4 มม.
เซนเซอร์ภาพ	1/3” Progressive Scan CMOS
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/ Scheduled/ Auto
FOV	• 2.8 mm:Horizontal FOV: 98.8°, Vertical FOV: 53.5°, Diagonal FOV: 117°• 4 mm:Horizontal : 75.2°, Vertical: 40.8°, Diagonal: 88.3°
Lens Mount	M12
DORI Distance	• 2.8 mmDetect: 154.2 ft (47 m)Observe: 62.3 ft (19 m)Recognize: 29.5 ft (9 m)Identify: 16.4 ft (5 m)• 4 mmDetect: 193.6 ft (59 m)Observe: 82 ft (25 m)Recognize: 39.4 ft (12 m)Identify: 19.7 ft (6 m)
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
ความละเอียดสูงสุด	1920x1080
Main Stream	• Frame Rate：50Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:1920x1080, 1280x960, 1280x720• Note: If the image rotation is set to 90°, the frame rate only supports up to 20fps.
Sub-Stream	• Frame Rate：50Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:848x480,704x576, 640x480, 640x360,352x288, 320x240• Note: If the image rotation is set to 90°, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Bit Rate	• Main Stream: 256 Kbps to 4 Mbps• Sub-Stream: 64 Kbps to 512 Kbps
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Alarm Linkage	• Upload to FTP server• Push Notifications• Send to Alarm Server• Email Alarm
Alarm	N/A
Reset Button	N/A
Protection	IP67 Waterproof, IK10 Vandal Proof
Environment Noise Filtering	Yes
Operating Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
Operating Humidity	95% or Less (Non-Condensing)
อุปกรณ์ในกล่อง	• VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
Material	Metal
Net Weight	0.5 Kg
Product Dimensions (L x W x H)	Ø4.5 × 3.4 in (Ø113.5 × 85.7mm)
Certifications	CE, NTRA, KC, FCC, VCCI, BSMI, ONVIF, IP67, IK10
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	0.005 Lux; 0 Lux with IR/White light
ระยะโฟกัส	2.8 มม. / 4 มม.
Aperture	F2.0
ช่วงปรับมุม	Pan: 0° to 353.5°, Tilt: 0° to 75°, Rotate: 0° to 355°
Integrated Infrared-White LED	• Quantity: 2• IR Range: 98 ft (30 m)3• White LED Range: 98 ft (30 m)3• IR Wavelength: 850 nm
การบีบอัดวิดีโอ	• Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264
H.264 Type	High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Image Settings	• Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance• Prevent Overexposure to Infrared Light• HLC Adjustable by Client Software
Image Enhancement	BLC/3D DNR/HLC/Smart IR
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
ONVIF	Yes
API	Open Network Video Interface (Profile S/T)
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Cloud	Yes
Smart Event	• Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• People Detection• Vehicle Detection
Basic Event	• Motion detection(Enhanced with Human & Vehicle Classification for more accurate alerts)• Camera Tampering• Exception (Illegal Login)
แหล่งจ่ายไฟ	• 12V DC ± 5%, Max. 6.3 W, 5.5 mm Coaxial Power Plug• PoE: 802.3af/at, class 0, Max. 6.7 W
ระยะเวลารับประกัน	3 ปี
