Name: TP-Link InSight S345ZI VIGI 4MP Outdoor IR Motorized Varifocal Bullet Network Camera
Brand: TP-Link

รายละเอียดสินค้า

รุ่น	InSight S345ZI
Type	Motorized Varifocal Lens
Web Browser	• Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and above
Audio Input	Built-in MicrophoneAudio In Interface
On-board Storage	Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB*
Storage Temperature	-40 °C to 60 °C (-40 °F to 140 °F)
Storage Humidity	95% or Less (Non-Condensing)
Wide Dynamic Range	120 dB
Client	VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Audio Output	Audio Out Interface
Audio Compression	Yes
Audio Sampling Rate	8 KHz
Audio Bit Rate	64 Kbps(G.711 alaw)
Built-in Microphone	Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in Speaker	N/A
Audio	1 Audio In, 1 Audio Out
กำลังไฟ	DC Power Port
เซนเซอร์ภาพ	1/2.9” Progressive Scan CMOS
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/ Scheduled/ Auto
FOV	2.7-13.5 mm:• Horizontal FOV: 29.6°-102.0° • Vertical FOV: 16.8°-53.8°• Diagonal FOV: 34.1°-122.8°
Lens Mount	Φ14
DORI Distance	2.7-13.5 mm:• Detect: 217-579 ft (66-207 m)• Observe: 92-282 ft (28-86 m)• Recognize: 43-135 ft (13-41 m)• Identify: 23-69 ft (7-21 m)
Illuminator Type	4× IR LED
Illuminator Distance	197 ft (60 m)
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
ความละเอียดสูงสุด	2688 x 1520
Main Stream	• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080Note: • If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream	• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:1280x720, 848x480, 704x576, 640x480, 640x360, 352x288, 320x240• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Bit Rate	• Main Stream: 256 Kbps to 6 Mbps• Sub-Stream: 64 Kbps to 1024 Kbps
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X Authentication
Alarm Linkage	• Memory Card Video Recording• Upload to FTP server• Push Notifications• Active Defence-Sound Alarm• Email Alarm• Send to Alarm Server• Alarm Out Device
Alarm	1 Alarm In, 1 Alarm Out
Reset Button	Yes
Protection	IP67 Weatherproof, IK10 Vandal Proof
Environment Noise Filtering	Yes
Operating Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
Operating Humidity	95% or Less (Non-Condensing)
อุปกรณ์ในกล่อง	• VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
Material	Metal
Net Weight	1.04 Kg
Product Dimensions (L x W x H)	10.1 × 3.9 × 4 in (256 × 100 × 101 mm)
Certifications	CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	0.005 Lux; 0 Lux with IR Light
ระยะโฟกัส	2.7-13.5 mm (5X Optical Zoom)
Aperture	F1.6
ช่วงปรับมุม	Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
การบีบอัดวิดีโอ	• Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264
H.264 Type	High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Image Settings	• Mirror• Rotation• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White balance• Prevent overexposure to infrared light • HLC Adjustable by Client Software
Image Enhancement	BLC/3D DNR/HLC/SmartIR
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
ONVIF	Yes
API	Open Network Video Interface (Profile G/S/T)
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Cloud	Yes
Smart Event	• Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• Object Abandoned Detection• Object Removal Detection• Loitering Detection• People Detection• Vehicle Detection• Abnormal Sound Detection• Scene Change Detection
Basic Event	• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)• Video Tampering Detection• Exception ( Illegal Login)
แหล่งจ่ายไฟ	DC• 12V DC ± 5%, Max.10.8 W, 5.5 mm Coaxial Power Plug• Recommended Power Supply:T120100-2C1 (for EU Regions)PoE• PoE: 802.3af/at, class 0, Max.12 WErP Information• Power consumption in networked standby when all wired network ports are connected: 2.1 W.
ระยะเวลารับประกัน	3 ปี

รายละเอียดสินค้า

รุ่น	InSight S345ZI
Type	Motorized Varifocal Lens
Web Browser	• Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and above
Audio Input	Built-in MicrophoneAudio In Interface
On-board Storage	Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB*
Storage Temperature	-40 °C to 60 °C (-40 °F to 140 °F)
Storage Humidity	95% or Less (Non-Condensing)
Wide Dynamic Range	120 dB
Client	VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Audio Output	Audio Out Interface
Audio Compression	Yes
Audio Sampling Rate	8 KHz
Audio Bit Rate	64 Kbps(G.711 alaw)
Built-in Microphone	Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in Speaker	N/A
Audio	1 Audio In, 1 Audio Out
กำลังไฟ	DC Power Port
เซนเซอร์ภาพ	1/2.9” Progressive Scan CMOS
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/ Scheduled/ Auto
FOV	2.7-13.5 mm:• Horizontal FOV: 29.6°-102.0° • Vertical FOV: 16.8°-53.8°• Diagonal FOV: 34.1°-122.8°
Lens Mount	Φ14
DORI Distance	2.7-13.5 mm:• Detect: 217-579 ft (66-207 m)• Observe: 92-282 ft (28-86 m)• Recognize: 43-135 ft (13-41 m)• Identify: 23-69 ft (7-21 m)
Illuminator Type	4× IR LED
Illuminator Distance	197 ft (60 m)
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
ความละเอียดสูงสุด	2688 x 1520
Main Stream	• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080Note: • If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream	• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:1280x720, 848x480, 704x576, 640x480, 640x360, 352x288, 320x240• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Bit Rate	• Main Stream: 256 Kbps to 6 Mbps• Sub-Stream: 64 Kbps to 1024 Kbps
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X Authentication
Alarm Linkage	• Memory Card Video Recording• Upload to FTP server• Push Notifications• Active Defence-Sound Alarm• Email Alarm• Send to Alarm Server• Alarm Out Device
Alarm	1 Alarm In, 1 Alarm Out
Reset Button	Yes
Protection	IP67 Weatherproof, IK10 Vandal Proof
Environment Noise Filtering	Yes
Operating Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
Operating Humidity	95% or Less (Non-Condensing)
อุปกรณ์ในกล่อง	• VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
Material	Metal
Net Weight	1.04 Kg
Product Dimensions (L x W x H)	10.1 × 3.9 × 4 in (256 × 100 × 101 mm)
Certifications	CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	0.005 Lux; 0 Lux with IR Light
ระยะโฟกัส	2.7-13.5 mm (5X Optical Zoom)
Aperture	F1.6
ช่วงปรับมุม	Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
การบีบอัดวิดีโอ	• Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264
H.264 Type	High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Image Settings	• Mirror• Rotation• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White balance• Prevent overexposure to infrared light • HLC Adjustable by Client Software
Image Enhancement	BLC/3D DNR/HLC/SmartIR
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
ONVIF	Yes
API	Open Network Video Interface (Profile G/S/T)
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Cloud	Yes
Smart Event	• Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• Object Abandoned Detection• Object Removal Detection• Loitering Detection• People Detection• Vehicle Detection• Abnormal Sound Detection• Scene Change Detection
Basic Event	• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)• Video Tampering Detection• Exception ( Illegal Login)
แหล่งจ่ายไฟ	DC• 12V DC ± 5%, Max.10.8 W, 5.5 mm Coaxial Power Plug• Recommended Power Supply:T120100-2C1 (for EU Regions)PoE• PoE: 802.3af/at, class 0, Max.12 WErP Information• Power consumption in networked standby when all wired network ports are connected: 2.1 W.
ระยะเวลารับประกัน	3 ปี
