Name: TP-Link InSight S355 VIGI 5MP Outdoor Full-Color Bullet Network Camera เลนส์ 2.8 มม.
Brand: TP-Link

รายละเอียดสินค้า

รุ่น	InSight S355
Type	Fixed Focal Lens
Web Browser	• Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and above
Audio Input	Yes (Built-in Microphone)
On-board Storage	Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB**
Storage Temperature	-40 °C to 60 °C (-40 °F to 140 °F)
Storage Humidity	95% or Less (Non-Condensing)
Wide Dynamic Range	120 dBNote: When People & Vehicle Analytics is enabled, only DWDR is supported.
Client	VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Audio Communication	Two-Way Audio
Audio Output	Yes (Built-in Speaker)
Audio Compression	Yes
Audio Sampling Rate	8KHz
Audio Bit Rate	64 Kbps(G.711 alaw)
Built-in Microphone	Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in Speaker	Yes
Audio	N/A
กำลังไฟ	DC Power Port
เลนส์ที่จำหน่าย	2.8 มม.
เซนเซอร์ภาพ	V1: 1/2.7” Progressive Scan CMOSV1.20:1/2.65” Progressive Scan CMOS
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/ Scheduled/ Auto
FOV	V1:• 2.8 mm: Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134°• 4 mm: Horizontal FOV: 88°, Vertical FOV: 46°, Diagonal FOV: 105.4°• 6 mm: Horizontal FOV: 57.3°, Vertical FOV: 31.3°, Diagonal FOV: 67.2°V1.20:• 2.8 mm: Horizontal FOV: 108.3°, Vertical FOV: 59.9°, Diagonal FOV: 126.8°
Lens Mount	M12*P 0.5
DORI Distance	• 2.8 mmDetect: 64 m (210 ft)Observe: 27 m (89 ft)Recognize: 13 m (43 ft)Identify: 6 m (20 ft)• 4 mmDetect: 80 m (262 ft)Observe: 33 m (108 ft)Recognize: 16 m (52 ft)Identify: 8 m (26 ft)• 6 mmDetect: 120 m (394 ft)Observe: 50 m (164 ft)Recognize: 24 m (79 ft)Identify: 12 m (39 ft)
Illuminator Type	• 2× IR LED• 2× White LED
Illuminator Distance	30 m (98 ft)
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
ความละเอียดสูงสุด	2880x1620
Main Stream	• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream	• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:848x480, 704x576, 640x480, 640x360, 352x288, 320x240• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Bit Rate	• Main Stream: 256 Kbps to 6 Mbps• Sub-Stream: 64 Kbps to 512 Kbps
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X authentication
Alarm Linkage	• Memory Card Video Recording• Upload to FTP server• Push Notifications• Active Defence-Sound Alarm• Active Defence-Light Alarm• Email Alarm• Send to Alarm Server
Alarm	N/A
Reset Button	Yes
Protection	IP67
Environment Noise Filtering	Yes
Operating Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
Operating Humidity	95% or Less (Non-Condensing)
อุปกรณ์ในกล่อง	• VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
Material	Metal
Net Weight	0.525 Kg
Product Dimensions (L x W x H)	7.2 × 2.9 × 2.9 in (184 × 74 × 74 mm)
Certifications	CE, NTRA, VCCI, KC, BSMI, FCC, IC
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	0.005 Lux; 0 Lux with IR/White light
ระยะโฟกัส	2.8 มม.
Aperture	F1.6
ช่วงปรับมุม	Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
การบีบอัดวิดีโอ	• Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264
H.264 Type	High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile*
H.265+	Main Stream Supported*
Image Settings	• Mirror• Rotation• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White balance• Prevent overexposure to infrared light • HLC Adjustable by Client Software
Image Enhancement	BLC/3D DNR/HLC/SmartIR
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
ONVIF	Yes
API	Open Network Video Interface (Profile G/S/T)
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Cloud	Yes
Smart Event	• Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• Object Abandoned Detection• Object Removal Detection• Loitering Detection• People Detection• Vehicle Detection• Abnormal Sound Detection• Scene Change Detection
Basic Event	• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)• Video Tampering Detection• Exception ( Illegal Login)
People & Vehicle Analytics	Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.§
แหล่งจ่ายไฟ	DC• 12V DC ± 5%, Max. 9.7 W, 5.5 mm Coaxial Power Plug• Recommended Power Supply:T120100-2C1 (for EU Regions)PoE• PoE: 802.3af/at, class 0, Max. 10.7 WErP Information• Power consumption in networked standby when all wired network ports are connected: 2.3 W.
ระยะเวลารับประกัน	3 ปี
