Omada 8-Port Gigabit Easy Smart Reverse PoE Switch
| รุ่น | RP108GE |
|---|---|
| System Requirements | Microsoft® Windows® for running Utility |
| Mac Address Table | 4 K |
| Jumbo Frame | 16 KB |
| พอร์ตเชื่อมต่อ | • 7× Passive PoE-in RJ45 Ports• 10/100/1000Mbps Auto-Negotiation• Voltage: 24/48 V (mixture is not supported)• Power pin of Ethernet cable: 4/5+ 7/8-• 1× Passive PoE-out RJ45 Port:• 10/100/1000Mbps Auto-Negotiation• Voltage: depending on the input voltage of PoE-in ports• Power pin of Ethernet cable: 4/5+ 7/8-• 1× DC Output Port• Voltage: 5/12 V |
| Network Media | • 10Base-T:UTP category 3, 4, 5 cable (maximum 100 m)EIA/TIA-568 100 Ω STP (maximum 100 m)• 100Base-TX:UTP category 5, 5e cable (maximum 100 m)EIA/TIA-568 100 Ω STP (maximum 100 m)• 1000Base-T:UTP category 5e cable (maximum 100 m)EIA/TIA-568 100 Ω STP (maximum 100 m) |
| Max. Power Consumption | • 3.98 W (with no PD connected)• 18.01 W (24 V with PD connected)• 32.74 W (48 V with PD connected) |
| L2 Features | • IGMP Snooping V1/V2/V3• Static Link Aggregation• Port Mirroring• Cable Diagnostics• Loop Prevention |
| VLAN | • Up to 32 VLANs simultaneously (out of 4K VLAN IDs)• MTU/Port/Tag VLAN |
| ขนาด (กว้าง × ลึก × สูง) | 6.2 × 3.9 × 1.0 in (158 × 99.1 × 25 mm) |
| Certification | FCC, CE, RoHS |
| อุปกรณ์ในกล่อง | • RP108GE• Power Cord• Installation Guide• Rubber Feet |
| Environment | • Operating Temperature: 0℃~40℃ (32℉~104℉)• Storage Temperature: -40℃~70℃ (-40℉~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing |
| Standards and Protocols | • IEEE802.3ab, IEEE802.3i, IEEE802.3p, IEEE802.3q, IEEE802.3x, IEEE802.3u• CSMA/CD |
| LED | Power, Link/Act LED |
| อัตราส่งต่อแพ็กเก็ต | 11.9 Mbps |
| ความสามารถในการสวิตช์ | 16 Gbps |
| IEEE Standards | IEEE802.3ab, IEEE802.3i, IEEE802.3pIEEE802.3q, IEEE802.3x, IEEE802.3u |
| อัตรารับส่งข้อมูล | • Ethernet: 10 Mbps (Half Duplex), 20 Mbps (Full Duplex)• Fast Ethernet: 100 Mbps (Half Duplex), 200 Mbps (Full Duplex)• Gigabit Ethernet: 2000 Mbps (Full Duplex) |
| Max Heat Dissipation | • 13.57 BTU/h (with no PD connected)• 61.41 BTU/h (24 V with PD connected)• 111.64 BTU/h (48 V with PD connected) |
| Quality of Service | • Port-based/802.1p/DSCP priority• 4 priority queues• Rate Limit• Storm Control |
| Transmission Method | Store-And-Forward |
| ระยะเวลารับประกัน | ตลอดอายุการใช้งาน (สิ้นสุด 3 ปีหลังผู้ผลิตประกาศหยุดผลิต) |
ยังไม่มีเอกสารจากผู้ผลิตสำหรับสินค้านี้
