- Interface
- • 24× 10/100/1000 Mbps RJ45 Ports
- 4× 10G SFP+ Slots
- 2× USB 2.0 Ports
- 1× RJ45 Console Port
- 1× USB Type-C Console Port
- 1× RJ45 Management Port
- Fan Quantity
- Four Internal Fixed Fans
- Power Supply
- Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz)
- Dimensions ( W x D x H )
- 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm)
- Mounting
- Rackmountable
- Max Power Consumption
- 28.4 W (220 V/50 Hz)
- Max Heat Dissipation
- 96.91 BTU/hr (220 V/50 Hz)
- Switching Capacity
- 128 Gbps per Unit
- Stacking
- • Stacking Number: 4
- Stacking Port
- 10G SFP+ Slot (all uplink ports can be used as stacking ports)
- Stack Bandwidth
- 20 Gbps Per Port (Full-Duplex)
- Packet Forwarding Rate
- 95.2 Mpps
- MAC Address Table
- 32 K
- Packet Buffer Memory
- 3 MB
- Jumbo Frame
- 9 KB
- Quality of Service
- • Class of Service
- 8 Queues of Priority
- Port Priority
- IEEE 802.1p Priority
- DSCP Priority
- Queue Min-Bandwidth
- Schedule Mode (SP, WRR, SP+WRR)
- Bandwidth Control
- Rate Limit
- Storm Control
- Voice VLAN
- User-Defined OUI
- Smoother Performance
- Action for Flows
- QoS remark (802.1P Remark, DSCP Remark)
- L2 and L2+ Features
- • Link Aggregation
- Spanning Tree Protocol
- Port-based and VLAN-based Loopback Detection
- 802.3x Flow Control
- Supports 2,048 IGMP groups
- ERPS
- Mirroring
- RSPAN
- MAC Address Table
- PIM-DM (IPv4)
- Multicast
- IGMP Snooping
- MLD Snooping
- L2 Multicast Table
- Fast Leave
- Multicast VLAN Registration (MVR)
- Static Multicast IP
- Multicast Filtering
- Advanced Features
- • Automatic Device Discovery †
- Batch Configuration †
- Batch Firmware Upgrading †
- Intelligent Network Monitoring †
- Abnormal Event Warnings †
- Unified Configuration †
- Reboot Schedule † ISP Features
- 802.3ah Ethernet Link OAM
- L2PT (Layer 2 Protocol Tunneling)
- Device Link Detect Protocol (DLDP)
- DDM
- sFlow
- VLAN
- • Max 4K VLAN Group (802.1q VLAN)
- 802.1Q Tagged VLAN
- MAC VLAN Entries
- 200
- Multicast VLAN
- Management VLAN
- Protocol VLAN
- Protocol Template 16, Protocol VLAN 12 entries
- VLAN VPN
- Voice VLAN
- Private VLAN
- Omada App
- Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Centralized Management
- • Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
- Cloud Access
- Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Zero-Touch Provisioning
- Yes. Requiring the use of the Omada Cloud-Based Controller.
- Management Features
- • Web-based GUI
- Command Line Interface (CLI) through console port, telnet
- SNMPv1/v2c/v3
- Trap/Inform
- RMON (1, 2, 3, 9 groups)
- SDM Template
- DHCP/BOOTP Client
- 802.1ab LLDP/LLDP-MED
- DHCP Auto Install
- Dual Image, Dual Configuration
- CPU Monitoring
- Cable Diagnostics
- Password Recovery
- SNTP
- System Log
- EEE
- Package Contents
- • SG6428X Switch
- 2× Power Cords
- RJ45 Console Cable
- Quick Installation Guide
- Rackmount Kit
- Rubber Feet
- System Requirements
- Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
- Environment
- • Operating Temperature: 0–45 ℃ (32–113 ℉);
- Storage Temperature
- -40–70 ℃ (-40–158 ℉)
- Operating Humidity
- 10–90% RH non-condensing
- Storage Humidity
- 5–90% RH non-condensing
