| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
|---|---|
| Centralized Management |
|
| Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features |
|
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Switching Capacity | 216 Gbps per Unit |
| Stacking | • Stacking Number: 4 |
| Stacking Port | 10G SFP+ Slot (all uplink ports can be used as stacking ports) |
| Packet Forwarding Rate | 160.7 Mpps |
| MAC Address Table | 32 K |
| Packet Buffer Memory | 3 MB |
| Jumbo Frame | 9 KB |
| Storage Temperature | -40–70 ℃ (-40–158 ℉) |
| Storage Humidity | 5–90% RH non-condensing |
| Stack Bandwidth | 20 Gbps Per Port (Full-Duplex) |
| Interface |
|
| PoE Ports (RJ45) | • Standard: 802.3at/af compliant |
| PoE+ Ports | 48 Ports, up to 30 W per port |
| Power Supply |
|
| PoE Power Budget | up to 1440 W**The total PoE budget varies with the power supply modules. |
| Max Power Consumption |
|
| L2 and L2+ Features |
|
| Advanced Features |
|
| Reboot Schedule † ISP Features |
|
| VLAN |
|
| MAC VLAN Entries |
|
| VLAN VPN (QinQ) |
|
| Protocol VLAN |
|
| Fan Quantity | Four Field-replaceable and Hot-swappable Fans |
| Dimensions ( W x D x H ) | 17.3 × 16.5 × 1.7 in (440 × 420 × 44 mm) |
| Mounting | Rackmountable |
| Package Contents |
|
| Environment | • Operating Temperature: 0–45 ℃ (32–113 ℉); |
| Operating Humidity | 10–90% RH non-condensing |
| Max Heat Dissipation |
|
| Quality of Service |
|
| ระยะเวลารับประกัน | ตลอดอายุการใช้งาน (สิ้นสุด 3 ปีหลังผู้ผลิตประกาศหยุดผลิต) |
