- Image Sensor
- 1/2.8” Progressive Scan CMOS
- Shutter Speed
- 1/3 to 1/10000 s
- Slow Shutter
- Yes
- Minimum Illumination
- Color: 0.005 Lux; 0 Lux with IR/White Light
- Day/Night Mechanism
- IR Cut Filter
- Day/Night Switch
- Unified/ Scheduled/ Auto
- Type
- Fixed Focal Lens
- Focal Length
- 2.8 mm/4 mm
- Aperture
- 2.8 mm: F1.6
- 4 mm
- F1.6
- FOV
- • 2.8 mm:
- Horizontal FOV
- 107.5°, Vertical FOV: 57.2°, Diagonal FOV: 128.7°• 4 mm:
- Horizontal FOV
- 84.4°, Vertical FOV: 44.3°, Diagonal FOV: 100.6°
- Lens Mount
- M12
- DORI Distance
- • 2.8 mm:
- Detect
- 52 m (170 ft)
- Observe
- 22 m (71 ft)
- Recognize
- 10 m (34 ft)
- Identify
- 5 m (17 ft)• 4 mm:
- Detect
- 70 m (230 ft)
- Observe
- 29 m (96 ft)
- Recognize
- 14 m (46 ft)
- Identify
- 7 m (23 ft)
- Range
- • Pan: 0° to 355°
- Tilt
- 0° to 75°
- IR LED
- • Quantity: 1
- Range
- 30m
- Wavelength
- 850nm
- White LED
- • Quantity: 1
- Range
- 30m
- Illuminator On/Off Control
- Auto/Scheduled/Always on/Always off
- Max. Resolution
- 2304 × 1296
- Main Stream
- • Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- Resolution
- 2304×1296, 2048×1280, 1920×1080, 1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Sub-Stream
- • Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- Resolution
- 704×576, 640×480, 352×288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Bit Rate Control
- CBR, VBR
- Video Compression
- • Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream
- H.265/H.264
- H.264 Type
- High Profile
- H.264+
- Main Stream Supported
- H.265 Type
- Main Profile
- H.265+
- Main Stream Supported
- Video Bit Rate
- • Main Stream: 256 Kbps to 4 Mbps
- Sub-Stream
- 64 Kbps to 512 Kbps
- Image Settings
- • Mirror
- Brightness
- Contrast
- Saturation
- Sharpness
- Exposure
- WDR
- White Balance
- Prevent Overexposure to Infrared Light
- HLC Adjustable by Client Software
- Rotation(90°/270°)
- Image Enhancement
- BLC/3D DNR/HLC/SmartIR
- Wide Dynamic Range
- DWDR
- SNR
- ≥ 52 dB
- Image Parameters Switch
- Yes
- Privacy Mask
- Up to 4 Masks
- ROI
- 1 Region
- OSD Setting
- Yes
- Audio Communication
- N/A
- Audio Input
- Yes
- Audio Output
- N/A
- Audio Compression
- Yes
- Audio Sampling Rate
- 8KHz
- Environment Noise Filtering
- Yes
- Audio Bit Rate
- 64 Kbps(G.711 alaw)
- Protocol
- • TCP/IP
- UDP
- ICMP
- HTTP
- HTTPS
- DHCP, DNS, RTSP
- NTP
- UPnP
- SSL/TLS
- FTP/SFTP
- RTP
- IPv4
- IPv6
- ARP
- ONVIF
- Yes
- API
- Open Network Video Interface (Profile S)
- Simultaneous Live View
- 3 Main Streams & 3 Sub-Streams
- Client
- VIGI App, VIGI Security Manager, Web UI
- Web Browser
- • Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
- Cloud
- Yes
- Security
- Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
- Smart Event
- • Intrusion Detection
- Line-Crossing Detection
- Region Entering Detection
- Region Exiting Detection
- Object Abandoned/Removal Detection
- Abnormal Sound Detection
- People Detection
- Vehicle Detection
- Basic Event
- • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
- Video Tampering Detection
- Exception ( Illegal Login)
- Alarm Linkage
- • White Light Flashing
- Message Push
- Network Interface
- 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
- Alarm
- N/A
- Reset Button
- N/A
- Power
- DC Power Port
- On-board Storage
- N/A
- Built-in Microphone
- Yes; Records Anything Going on within a 15-ft Radius of the Camera
- Built-in Speaker
- N/A
- Audio
- N/A
- Operating Temperature
- -30–60 °C
- Storage Temperature
- -40–60 °C
- Operating Humidity
- 95% or Less (Non-Condensing)
- Storage Humidity
- 95% or Less (Non-Condensing)
- Package Content
- • VIGI Network Camera
- Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
- Material
- Plastic
- Net Weight
- 0.29 Kg
- Gross Weight
- 0.47 Kg
- Power Supply
- • 12V DC ± 5%, Max. 4.7 W, 5.5mm Coaxial Power Plug
- PoE
- 802.3af/at, class 0, Max. 5.5 W
- Protection
- IP67 Waterproof, IK10 Vandal Proof
- Product Dimensions (L x W x H)
- 115× 115× 86 mm (4.53× 4.53× 3.39 in)
- Certifications
- CE, NTRA, VCCI, BSMI
- รหัสสินค้า (SKU)
- VIGI C230(4MM)
