- Image Sensor
- 1/3” Progressive Scan CMOS
- Shutter Speed
- 1/3 to 1/10000 s
- Slow Shutter
- Yes
- Minimum Illumination
- Color: 0.005 Lux; 0 Lux with IR/White Light
- Day/Night Mechanism
- IR Cut Filter
- Day/Night Switch
- Unified/ Scheduled/ Auto
- Type
- Fixed Focal Lens
- Focal Length
- 2.8 mm/4 mm
- Aperture
- 2.8 mm: F1.6
- 4 mm
- F1.6
- FOV
- 2.8 mm:
- Horizontal FOV
- 95.7°, Vertical FOV: 51.7°, Diagonal FOV: 113.0°
- Horizontal FOV
- 79.7°, Vertical FOV: 42.9°, Diagonal FOV: 93.9°
- Lens Mount
- M12
- DORI Distance
- 2.8 mm:
- Detect
- 64 m (209 ft)
- Observe
- 27 m (87 ft)
- Recognize
- 13 m (42 ft)
- Identify
- 6 m (21 ft)
- Detect
- 80 m (262 ft)
- Observe
- 33 m (109 ft)
- Recognize
- 16 m (52 ft)
- Identify
- 8 m (26 ft)
- Range
- Pan: 0° to 355°
- Tilt
- 0° to 75°
- IR LED
- Quantity: 1
- Range
- 30m
- Wavelength
- 850nm
- White LED
- Quantity: 1
- Range
- 30m
- Illuminator On/Off Control
- Auto/Scheduled/Always on/Always off
- Max. Resolution
- 2560 × 1440
- Main Stream
- Frame Rate:
- 50Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 2560×1440,2304×1296, 2048×1280, 1920×1080, 1280×720
- Note
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Sub-Stream
- Frame Rate:
- 50Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 640×480,352×288, 320×240
- Note
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Bit Rate Control
- CBR, VBR
- Video Compression
- Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream
- H.265/H.264
- H.264 Type
- High Profile
- H.264+
- Main Stream Supported
- H.265 Type
- Main Profile
- H.265+
- Main Stream Supported
- Video Bit Rate
- Main Stream: 256 Kbps to 4 Mbps
- Sub-Stream
- 64 Kbps to 512 Kbps
- Image Settings
- Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,
- White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°)
- Image Enhancement
- BLC/3D DNR/HLC/SmartIR
- Wide Dynamic Range
- DWDR
- SNR
- ≥ 52 dB
- Image Parameters Switch
- Yes
- Privacy Mask
- Up to 4 Masks
- ROI
- 1 Region
- OSD Setting
- Yes
- Audio Communication
- N/A
- Audio Input
- Yes
- Audio Output
- N/A
- Audio Compression
- Yes
- Audio Sampling Rate
- 8KHz
- Environment Noise Filtering
- Yes
- Audio Bit Rate
- 64 Kbps(G.711 alaw)
- Protocol
- TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS,
- RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
- ONVIF
- Yes
- API
- Open Network Video Interface (Profile S)
- Simultaneous Live View
- 3 Main Streams & 3 Sub-Streams
- Client
- VIGI App, VIGI Security Manager, Web UI
- Web Browser
- Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
- Cloud
- Yes
- Security
- Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
- Smart Event
- • Area Intrusion Detection
- Line-Crossing Detection
- People Detection
- Vehicle Detection
- Region Entering Detection
- Region Exiting Detection
- Object Abandoned Detection
- Object Removal Detection
- Abnormal Sound Detection
- Basic Event
- • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
- Video Tampering Detection
- Exception ( Illegal Login)
- Alarm Linkage
- White Light Flashing, Message Push
- Network Interface
- 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
- Alarm
- N/A
- Reset Button
- Yes
- Power
- DC Power Port
- On-board Storage
- Built-in Memory Card Slot, Support MicroSD Card, Up to 512 GB
- Built-in Microphone
- Yes; Records Anything Going on within a 15-ft Radius of the Camera
- Built-in Speaker
- N/A
- Audio
- N/A
- Operating Temperature
- -30–60 °C
- Storage Temperature
- -40–60 °C
- Operating Humidity
- 95% or Less (Non-Condensing)
- Storage Humidity
- 95% or Less (Non-Condensing)
- Package Content
- VIGI Network Camera
- Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
- Material
- Plastic
- Net Weight
- 0.28 Kg
- Gross Weight
- 0.46 Kg
- Power Supply
- 12V DC ± 5%, Max. 5.4 W, 5.5mm Coaxial Power Plug
- PoE
- 802.3af/at, class 0, Max. 6 W
- Protection
- IP67, IK10
- Product Dimensions (L x W x H)
- 115× 86× 115 mm
- Certifications
- CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
