- Image Sensor
- 1/2.7” Progressive Scan CMOS
- Shutter Speed
- 1/3 to 1/10000 s
- Slow Shutter
- Yes
- Minimum Illumination
- 0.005 Lux; 0 Lux with IR/white light
- Day/Night Mechanism
- IR Cut Filter
- Day/Night Switch
- Unified/ Scheduled/ Auto
- Type
- Fixed Focal Lens
- Focal Length
- 2.8/4 mm
- Aperture
- 2.8 mm: F1.6
- 4 mm
- F1.6
- FOV
- 2.8mm:
- Horizontal FOV
- 109°, Vertical FOV: 57°, Diagonal FOV: 128°
- Horizontal FOV
- 90°, Vertical FOV: 48°, Diagonal FOV: 107°
- Lens Mount
- M12*P 0.5
- DORI Distance
- 2.8 mm
- Detect
- 64 m (209 ft)
- Observe
- 27 m (87 ft)
- Recognize
- 13 m (42 ft)
- Detect
- 80 m (262 ft)
- Observe
- 33 m (109 ft)
- Recognize
- 16 m (52 ft)
- Identify
- 8 m (26 ft)
- Range
- Pan: 0° to 360°, Tilt: 0° to 85°
- IR LED
- Quantity: 2
- Range
- 30m
- Wavelength
- 850nm
- White LED
- Quantity: 2
- Range
- 30m
- Illuminator On/Off Control
- Auto/Scheduled/Always on/Always off
- Max. Resolution
- 2880 X 1620
- Main Stream
- Frame Rate：
- 50Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 2880×1620,2688×1520, 2304×1296, 2048×1280, 1920×1080,1280×720
- Note
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Sub-Stream
- Frame Rate：
- 50Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 704×576,640×480, 352×288, 320×240
- Note
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Bit Rate Control
- CBR, VBR
- Video Compression
- Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream
- H.265/H.264
- H.264 Type
- Main Profile/High Profile
- H.264+
- Main Stream Supported
- H.265 Type
- Main Profile△
- H.265+
- Main Stream Supported△
- Video Bit Rate
- Main Stream: 256 Kbps to 6 Mbps
- Sub-Stream
- 64 Kbps to 512 Kbps
- Image Settings
- Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°)
- Image Enhancement
- BLC/3D DNR/HLC/SmartIR
- Wide Dynamic Range
- 120 dB
- SNR
- ≥ 52 dB
- Image Parameters Switch
- Yes
- Privacy Mask
- Up to 4 Masks
- ROI
- 1 Region
- OSD Setting
- Yes
- Audio Communication
- Two-Way Audio
- Audio Input
- Yes
- Audio Output
- Yes
- Audio Compression
- Yes
- Audio Sampling Rate
- 8KHz
- Environment Noise Filtering
- Yes
- Audio Bit Rate
- 64 Kbps(G.711 alaw)
- Protocol
- • TCP/IP
- UDP
- ICMP
- HTTP
- HTTPS
- DHCP, DNS, RTSP
- NTP
- UPnP UDP
- SSL/TLS
- SNMP
- IEEE 802.1x
- ONVIF
- Yes
- API
- Open Network Video Interface (Profile S)
- Simultaneous Live View
- 3 Main Streams & 3 Sub-Streams
- Client
- VIGI App, VIGI Security Manager, Web UI
- Web Browser
- Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
- Cloud
- Yes
- Security
- Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
- Smart Event
- Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection
- Basic Event
- Motion Detection, Video Tampering Detection, Exception ( Illegal Login), Scene Change Detection
- Alarm Linkage
- Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
- Linkage Method
- N/A
- Output Notification
- Message Push
- People & Vehicle Analytics
- Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
- Multi-Target-Type Detection
- Supports Simultaneous Detection and Capture of Human Body and Vehicle
- Face Capture
- N/A
- Face Comparison
- N/A
- Network Interface
- 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
- Alarm
- N/A
- Reset Button
- Yes
- Power
- DC Power Port
- On-board Storage
- Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB
- Built-in Microphone
- Yes; Records Anything Going on within a 15-ft Radius of the Camera
- Built-in Speaker
- Yes
- Audio
- N/A
- Operating Temperature
- -30–60 °C
- Storage Temperature
- -40–60 °C
- Operating Humidity
- 95% or Less (Non-Condensing)
- Storage Humidity
- 95% or Less (Non-Condensing)
- Package Content
- VIGI Network Camera
- Quick Start Guide
- Mounting Accessories
- Material
- Plastic
- Net Weight
- 0.24 Kg
- Gross Weight
- 0.4 Kg
- Power Supply
- 12V DC ± 5%, Max. 9 W, 5.5mm Coaxial Power Plug
- PoE
- 802.3af/at, class 0, Max. 10.5 W
- Protection
- N/A
- Product Dimensions (L x W x H)
- 123x 84x 123 mm
- Certifications
- CE, NTRA, VCCI, KC, BSMI, FCC, IC
