- Image Sensor
- 1/3” Progressive Scan CMOS
- Shutter Speed
- 1/3 to 1/10000 s
- Slow Shutter
- Yes
- Aperture
- 4 mm: F1.6
- Lens
- Fixed focal lens (4 mm)
- Lens Mount
- M12
- Minimum Illumination
- Color: 0.005 Lux; 0 Lux with IR/white light
- Day/Night Mechanism
- IR Cut Filter
- Day/Night Switch
- Unified/ Scheduled/ Auto
- Digital Noise Reduction
- 3D DNR
- WDR
- DWDR
- Weatherproof Rating
- IP66
- Viewing Angle
- (4mm) Horizontal FOV: 80°, Vertical FOV: 43.2°, Diagonal FOV: 94.2°
- Type
- Fixed Focal Lens
- Focal Length
- 4 mm
- Aperture
- F1.6
- FOV
- 4mm:
- Horizontal FOV
- 79°, Vertical FOV: 43°, Diagonal FOV: 93°
- DORI Distance
- 4 mm:
- Detect
- 80 m (262 ft)
- Observe
- 33 m (109 ft)
- Recognize
- 16 m (52 ft)
- Identify
- 8 m (26 ft)
- Pan/tilt Range
- Pan: 0° to 350°, Tilt: 0° to 120°
- Pan/tilt Speed
- Pan Speed:
- Configurable from 1° to 55°/s; Preset Speed
- 55°/s
- Tilt Speed
- Configurable from 1° to 40°/s, Preset Speed 40°/s
- Manual Control Speed
- Configurable from 8° to 35°/s
- Presets
- 300
- Patrol Scan
- 8 patrols, up to 8 presets for each patrol
- Power-off Memory
- Yes
- Park Action
- Yes
- 3D Positioning
- Preset, Patrol Scan
- Range
- Pan: 0° to 348°
- Tilt
- 0° to 120°
- IR LED
- Quantity: 2
- Range
- 30m
- Wavelength
- 850nm
- White LED
- Quantity: 2
- Range
- 30m
- Illuminator On/Off Control
- Auto/Scheduled/Always on/Always off
- Max. Resolution
- 2560 X 1440
- Main Stream
- Frame Rate:
- 50Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720
- Note
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Sub-Stream
- Frame Rate:
- 50Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 640×480, 352×288, 320×240
- Note
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- Bit Rate Control
- CBR, VBR
- Video Compression
- Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream
- H.265/H.264
- H.264 Type
- Main Profile/High Profile
- H.264+
- Main Stream Supported
- H.265 Type
- Main Profile
- H.265+
- Main Stream Supported
- Video Bit Rate
- Main Stream: 256 Kbps to 4 Mbps
- Sub-Stream
- 64 Kbps to 512 Kbps
- Image Settings
- Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,
- White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°)
- Image Enhancement
- BLC/3D DNR/HLC/SmartIR
- Wide Dynamic Range
- DWDR
- SNR
- ≥ 52 dB
- Image Parameters Switch
- Yes
- Privacy Mask
- Up to 4 Masks
- ROI
- 1 Region
- OSD Setting
- Yes
- Audio Communication
- Two-Way Audio
- Audio Input
- Yes
- Audio Output
- Yes
- Audio Compression
- Yes
- Audio Sampling Rate
- 8KHz
- Environment Noise Filtering
- Yes
- Audio Bit Rate
- 64 Kbps(G.711 alaw)
- Protocol
- • TCP/IP
- UDP
- ICMP
- HTTP
- HTTPS
- DHCP
- DNS
- RTSP
- NTP
- UPnP UDP
- SSL/TLS
- FTP/SFTP
- RTP
- IPv4
- IPv6
- ARP
- SNMP
- IEEE 802.1x
- ONVIF
- Yes
- API
- Open Network Video Interface (Profile S)
- Simultaneous Live View
- 3 Main Streams & 3 Sub-Streams
- Client
- VIGI App, VIGI Security Manager, VIGI NVR, Web
- Web Browser
- Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
- Cloud
- Yes
- Security
- Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
- Network Storage
- NAS (NFS, SMB/ CIFS)
- Smart Event
- • Area Intrusion Detection
- Line-Crossing Detection
- People Detection
- Vehicle Detection
- Region Entering Detection
- Region Exiting Detection
- Object Abandoned Detection
- Object Removal Detection
- Abnormal Sound Detection
- Basic Event
- • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
- Video Tampering Detection
- Exception ( Illegal Login)
- Alarm Linkage
- Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
- Linkage Method
- N/A
- Output Notification
- Message Push
- Network Interface
- 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
- Audio Output
- N/A
- Alarm
- N/A
- Reset Button
- Yes
- Power
- DC Power Port
- Button
- Reset Button
- On-board Storage
- Built-In Memory Card Slot, Support MicroSD Card,
- Up to 512 GB
- Built-in Microphone
- Yes
- Built-in Speaker
- Yes
- Audio
- N/A
- Operating Temperature
- -30–60 °C
- Storage Temperature
- -40–60 °C
- Operating Humidity
- 95% or Less (Non-Condensing)
- Storage Humidity
- 95% or Less (Non-Condensing)
- Package Content
- VIGI Network Camera
- Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
- Dimensions( H X W X D )
- 120 × 172 × 198 mm
- Material
- Plastic
- General Features
- Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
- Max. Power Consumption
- 12V DC: Max 14W
- PoE
- Class 4
- Power Supply
- 12V DC ± 5%, 5.5mm Coaxial Power Plug
- PoE (802.3af/at, class 4)
- Protection
- IP66
- Product Dimensions (L x W x H)
- 120 × 172 × 198 mm
- Certifications
- CE, RCM, BSMI, VCCI, RoHS, NTRA, KC
- Video Compression
- Main stream: H.265+/H.265/H.264+//H.264
- Sub-Stream
- H.265/H.264
- Frame Rate & Resolutions
- Main Stream
- Frame Rate
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720
- Sub-Stream
- Frame Rate
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Resolution
- 640×480, 352×288, 320×240
- Image Settings
- Mirror, Brightness, Contrast, Saturation, Sharpness,
- Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation (90°/270°)
- Day/Night Switch
- Day/Night/Auto/Schedule-Switch
- Smart Event
- Human & Vehicle Classification, Area Intrusion
- Detection, Line-Crossing Detection, People
- Detection, Vehicle Detection, Region Entering
- Detection, Region Exiting Detection, Object
- Abandoned Detection, Object Removal Detection
- Basic Event
- Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
- Region of Interest
- 1 Region
