- IP Video Input
- 16-Channel
- Incoming Bandwidth
- 160 Mbps
- Outgoing Bandwidth
- 160 Mbps
- HDMI Output Resolution
- 1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz
- VGA Output Resolution
- 1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz
- Video Output Mode
- HDMI/VGA Simultaneous Output
- Multi-View Display
- 1/4/6/8/9/16
- Audio Compression
- G.711A/G.711U/G.726
- Video Compression
- H.265+/H.265/ H.264+/H.264
- Record Resolution
- 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
- 2CIF/CIF/QCIF
- Synchronous Playback
- 16-Channel †
- 30fps
- 2-ch@8MP, 4-ch@5MP, 5-ch@4MP, 6-ch@3MP
- Record Mode
- Manual Recording, Scheduling Recording, Motion Detection Recording
- Playback Mode
- Instant Playback, Regular Playback, Tag Playback, Event Playback
- Backup Mode
- Regular Backup, Video Clip Backup
- Playback Function
- Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full
- Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off
- Protocol
- UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
- Mobile Phone Access
- Android, iOS
- Web Browser
- Chrome (57+), Firefox (52+), Edge (91+)
- Interoperability
- ONVIF Profile S, CGI
- Network Interface
- 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
- USB Interface
- 1 Front USB 2.0 Port, 1 Rear USB 3.0 Port
- Audio Interface
- 1-ch RCA Input; 1-ch RCA Output
- Alarm In/Out
- 6/4
- Serial Interface
- N/A
- Power
- 1× DC Jack
- Reset Button
- 1
- Speaker
- N/A
- eSATA
- 1
- HDMI
- 1
- VGA
- 1
- SATA
- 2 SATA Interfaces
- Capacity
- Up to 16 TB Capacity for Each HDD*
- Standard
- 802.3at/af Compliant
- Interface
- 1- 16, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
- PoE Budget
- 90 △ W Available for All PoE+ Ports, 30 W Max per Port
- General Alarm
- • Motion Detection
- Video Tampering
- Scene Change Detection
- Line-Crossing Detection
- Intrusion Detection
- Region Entering Detection
- Region Exiting Detection
- Loitering Detection
- Object Abandoned/Removal Detection
- Vehicle Detection
- Human Detection
- Abnormal Sound Detection
- Smart Frame
- Note
- The alarm function requires the use of a camera.
- Anomaly Alarm
- • Video Loss
- Offline and IP Conflict
- Disk Exception
- Login Exception
- Fan Exception
- Note
- The alarm function requires the use of a camera.
- Alarm Linkage
- • Recording
- White Light Alarm
- Buzzer
- Log
- Audible Alarm
- Note
- The alarm function requires the use of a camera.
- Storage Temperature
- -40–70 °C
- Storage Humidity
- 10%~90% RH Non-Condensing
- Package Content
- • VIGI Network Video Recorder
- Power Adapter
- Power Cable
- HDD Power Cables
- HDD Data Cables
- Mounting Accessories
- Mouse
- Quick Installation Guide
- Working Temperature
- NVR: -10–55 °C
- Power Adapter
- 0–40 °C
- Working Humidity
- 10%~90% RH Non-Condensing
- Dimensions( W X D X H )
- 13.0 × 11.2 × 1.8 in (330 × 285 × 45 mm)
- Net Weight
- 2.2 Kg §
- Gross Weight
- 4.2 Kg §
- Power Supply
- 53.5V DC/2.43A
- Max. Power Consumption
- 6.2 W (Without Disk)
- 40 W (With Disk)
- Certifications
- CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
- รหัสสินค้า (SKU)
- VIGI NVR2016H-16P
