- SIM Type
- 1× Nano SIM Card
- Frequency
- • Downlink: 300 Mbps;
- Uplink
- 50 Mbps
- Access Control
- Source/Destination IP Based Access Control
- Filtering
- • Web Group Filtering †
- URL Filtering
- Web Security †
- ARP Inspection
- • Sending GARP Packets
- ARP Scanning †
- IP-MAC Binding
- Attack Defense
- • TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
- Interface
- • 1 Gigabit SFP WAN/LAN Port
- 1 Gigabit WAN Port
- 4 Gigabit LAN/WAN Ports
- Network Media
- • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
- 100BASE-TX
- UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
- 1000BASE-T
- UTP category 5, 5e, 6 cable (Max 100 m)
- Button
- Reset Button
- Power Supply
- 12VDC / 2A Power Adapter
- Wi-Fi Frequency & Signal Rate
- • 2.4 GHz: 574 Mbps
- 5 GHz
- 2402 Mbps (HE160)
- Flash
- 128 MB NAND
- DRAM
- 512 MB DDR4
- LED
- SYS, WLAN, SFP, LTE Signal, WAN (1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act)
- Dimensions ( W x D x H )
- 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not
- included)
- Antenna
- • Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas
- LTE
- Two 4.0dBi omnidirectional detachable antennas
- Mounting
- Desktop/Wall-Mounting
- Max Power Consumption
- EU: 17.3W
- GRE
- • Unencrypted: 545.3Mbps
- Encrypted
- 282.6Mbps
- WireGuard VPN
- 387.7Mbps
- Concurrent Session
- 150,000
- New Sessions /Second
- 5,100
- NAT (Static IP)
- 947.1Mbps / 940.1Mbps
- NAT(DHCP)
- 949.2Mbps / 941.1Mbps
- NAT(PPPoE)
- 942.6Mbps / 941.1Mbps
- NAT (L2TP)
- 875.4Mbps / 892.0Mbps
- NAT (PPTP)
- 881.2Mbps / 895.8Mbps
- IPsec VPN Throughput
- • ESP-SHA1-AES256: 652.2Mbps
- ESP-SHA256-AES256
- 654.4Mbps
- ESP-SHA384-AES256
- 646.5Mbps
- ESP-SHA512-AES256
- 670.5 Mbps
- OpenVPN
- 115.5Mbps
- L2TP VPN Throughput
- • Unencrypted: 990.0Mbps
- Encrypted
- 475.0Mbps
- PPTP VPN Throughput
- • Unencrypted: 1177.9Mbps
- Encrypted
- 177.4Mbps
- SSL VPN Throughput
- 122.5Mbps
- 66 Byte Packet forwarding rate
- 1,453,489 pps / 1,453,488 pps
- 1,518 Byte Packet forwarding rate
- 81274 pps / 91275 pps
- Advanced Functions
- • Seamless Roaming
- Mesh (with EAP that supports Mesh)
- OFDMA
- Beamforming
- MU-MIMO
- Rate Limit
- Based on SSID/Client
- Airtime Fairness
- Wireless Encryption
- WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
- Multiple SSIDs
- 16 in total (8 per radio)
- Guest Network
- Support
- WAN Connection Type
- • Static IP
- Dynamic IP
- PPPoE (supports MRU Configuration)
- PPTP
- L2TP
- MAC Clone
- Modify WAN Address
- DHCP
- • DHCP Server
- DHCPv6 PD Server (only in Standalone Mode)
- DHCP Options Customization
- DHCP Address Reservation
- Multi-IP Interfaces
- Multi-Net DHCP
- SMS
- Receive / Send SMS
- IPv6
- StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
- VLAN
- 802.1Q VLAN
- IPTV
- IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
- ACL
- IP/Port/Protocol/Domain Name Filtering
- Advanced Routing
- • Static Routing
- Policy Routing
- RIP †
- OSPF †
- Bandwidth Control
- IP-Based Bandwidth Control
- Load Balance
- • Intelligent Load Balance
- Application Optimized Routing
- Link Backup(Timing, Failover)
- Online Detection
- NAT
- • One-to-One NAT
- Multi-Net NAT
- Virtual Server
- Port Triggering †
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP
- Session Limit
- IP-Based Session Limit
- GRE
- Only in Standalone Mode
- SSL VPN
- 50 Tunnels
- IPsec VPN
- • 100 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
- IPsec Failover
- IKE v1/v2
- MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
- PPTP VPN
- • PPTP VPN Server
- PPTP VPN Client (10) △
- 50 Tunnels
- PPTP with MPPE Encryption
- L2TP VPN
- • L2TP VPN Server
- L2TP VPN Client (10) △
- 50 Tunnels
- L2TP over IPSec
- OpenVPN
- • OpenVPN Server
- OpenVPN Client (5) △
- 55 OpenVPN Tunnels
- “Certificate + Account” Mode
- Full Mode
- Web Authentication
- • No Authentication
- Simple Password §
- Hotspot (Local User / Voucher § / SMS § / Radius § )
- External Radius Sever
- External Portal Sever §
- LDAP
- Omada App
- Yes.
- Centralized Management
- • Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Cloud Access
- Yes.
- Service
- Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
- Maintenance
- • Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3
- Diagnostics (Ping & Traceroute) †
- NTP Synchronize †
- Port Mirroring
- CLI (only in Standalone Mode)
- Syslog Support
- Zero-Touch Provisioning
- Yes. Require the use of Omada Cloud-Based Controller.
- Management Features
- • Automatic Device Discovery
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
- Captive Portal Configuration
- Certification
- CE, FCC, RoHS
- Package Contents
- • ER706W-4G
- Power Adapter
- Quick Installation Guide
- System Requirements
- • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
- MAC OS, NetWare, UNIX or Linux
- Environment
- • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature
- -40 °C to 70 °C (-40 °F to 158 °F)
- Operating Humidity
- 10% to 90% non-condensing
- Storage Humidity
- 5% to 90% non-condensing
