- Test data – UniFi Application Suite
- Full
- UniFi Devices
- 200+
- Client Devices
- 200+
- WiFi
- –
- High Availability
- Shadow Mode
- Multi-WAN Load Balancing
- Yes
- Application-Aware Firewall
- Yes
- Dimensions
- 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
- Weight
- 3.9 kg (8.6 lb)
- Enclosure material
- Aluminium CNC, SGCC steel
- Mount material
- SGCC steel
- Processor
- Quad-core ARM® Cortex®-A57 at 1.7 GHz
- System memory
- 4 GB DDR4
- On-board storage
- 16 GB eMMC
- (1) 10G SFP+ portWAN
- (1) GbE RJ45 port
- (1) 10G SFP+ port
- IDS/IPS throughput
- 3.5 Gbps*
- *Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
- Power method
- (1) Universal AC input, 100—240V AC, 50/60 Hz
- (1) USP-RPS DC input
- Power supply
- AC/DC, internal, 50W
- Supported voltage range
- 100—240V AC
- Max. power consumption
- 33W
- ESD/EMP protection
- Air: ± 15kV, contact: ± 8kV
- LCM display
- (1) 1.3″ touchscreen
- Button
- Factory reset
- Ambient operating temperature
- -10° to 40° C (14° to 104° F)
- Ambient operating humidity
- 5 to 95% noncondensing
- Certifications
- CE, FCC, IC
- Performance
- Redundant WAN with failover and load balancing
- WiFi QoS with UniFi APs
- Application, domain, and country-based QoS
- Application and device type identification
- Additional internet failover with LTE Backup
- Internet quality and outage reporting
- Next-generation security
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- Full stateful firewall
- Advanced networking
- License-free SD-WAN
- WireGuard, L2TP and OpenVPN server
- OpenVPN client
- OpenVPN and IPsec site-to-site VPN
- One-click Teleport and Identity VPN
- Policy-based WAN and VPN routing
- DHCP relay
- Customizable DHCP server
- IGMP proxy
- IPv6 ISP support
- Ethernet
- Link/activity
- Green
- 1G
- Amber
- 10/100M
- SFP+
- Link/activity
- White
- 10G
- Green
- 1G
- HDD
- White: disk activity
- Amber
- disk error
- RPS
- Blue: ready
- รหัสสินค้า (SKU)
- UQT-UDM-PRO
- หมวดหมู่
- แอคเซสพอยต์ & Wi-Fi
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
