- Standards and Protocols
- • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
- TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP
- Interface
- • 2 Gigabit SFP WAN/LAN ports
- 1 Gigabit WAN port
- 1 Gigabit LAN/WAN port
- 8 Gigabit LAN ports
- Network Media
- • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)
- EIA/TIA-568 100Ω STP (Max 100 m)
- 100BASE-TX
- UTP category 5, 5e cable (Max 100 m)
- EIA/TIA-568 100Ω STP (Max 100 m)
- 1000BASE-T
- UTP category 5, 5e, 6 cable (Max 100 m)
- Fan Quantity
- Fanless
- Button
- Reset Button
- Power Supply
- 53.5VDC/2.43A Adapter
- PoE Budget
- 8 ports PoE+ output, 110 W PoE Budget
- Flash
- 8Mb Nor + 4 GB EMMC
- DRAM
- 1 GB DDR3
- LED
- PWR, SYS, CLOUD, PoE Max, SFP 1, SFP 2, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
- Dimensions ( W x D x H )
- 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
- Protection
- 4 kV surge protection
- Enclosure
- Steel
- Mounting
- Desktop/Wall-mount
- Max Power Consumption
- • 133.2W with PoE Max
- 13.88W without PoE
- Concurrent Session
- 24,980
- New Sessions /Second
- 1,900
- NAT (Static IP)
- 935.5 Mbps / 942.1 Mbps
- NAT(DHCP)
- 940.2 Mbps / 941.7 Mbps
- NAT(PPPoE)
- 913.1 Mbps / 935.2 Mbps
- NAT (L2TP)
- 545.0 Mbps / 912.7 Mbps
- NAT (PPTP)
- 523.0 Mbps / 912.8 Mbps
- IPsec VPN Throughput (AES256)
- 168.5 Mbps
- IPsec VPN Throughput
- AES256: 168.5 Mbps
- OpenVPN
- 34 Mbps
- L2TP VPN Throughput
- • Unencrypted: 845.3 Mbps
- Encrypted
- 333.2 Mbps
- PPTP VPN Throughput
- • Unencrypted: 1012.6 Mbps
- Encrypted
- 401.4 Mbps
- 66 Byte Packet forwarding rate
- 154,069 pps / 156,977 pps
- 1,518 Byte Packet forwarding rate
- 81,193 pps / 81,193 pps
- WAN Connection Type
- • Static IP
- Dynamic IP
- PPPoE
- PPTP
- L2TP
- MAC Clone
- Modify WAN MAC Address
- DHCP
- • DHCP Server
- DHCP Address Reservation
- Multi-IP Interfaces
- Multi-Net DHCP
- IPv6
- support
- VLAN
- 802.1Q VLAN
- IPTV
- IGMP v2/v3 Proxy
- ACL
- IP/Port/Protocol/Domain Name Filtering
- Advanced Routing
- • Static Routing
- Policy Routing
- Bandwidth Control
- IP/Port-based Bandwidth Control
- Load Balance
- • Intelligent Load Balance
- Application Optimized Routing
- Link Backup
- Online Detection
- NAT
- • Multi-Net NAT
- Virtual Server
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP
- Session Limit
- IP-based Session Limit
- SSL VPN
- –
- IPsec VPN
- • 20 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- AES128, AES192, AES256 Encryption Algorithm
- IKE v1/v2
- SHA1, SHA2 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
- PPTP VPN
- • PPTP VPN Server
- PPTP VPN Client (10)
- 16 Tunnels
- PPTP with MPPE Encryption
- L2TP VPN
- • L2TP VPN Server
- L2TP VPN Client (10)
- 16 Tunnels
- L2TP over IPSec
- OpenVPN
- • OpenVPN Server
- OpenVPN Client (10)§
- 16 OpenVPN Tunnels
- Filtering
- URL Filtering
- ARP Inspection
- –
- Attack Defense
- • TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
- Access Control
- Source/Destination IP Based Access Control
- Web Authentication
- • No Authentication
- Simple Password
- Hotspot (Local User / Voucher / SMS / Radius)
- External Radius Sever
- External Portal Sever
- Omada App
- Yes
- Centralized Management
- • Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Omada Cloud-Based Controller
- Cloud Access
- Yes
- Service
- Dynamic DNS (Dyndns, No-IP)
- Maintenance
- • Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3
- Syslog Support
- Zero-Touch Provisioning
- Yes. Requiring the use of Omada Cloud-Based Controller.
- Management Features
- • Automatic Device Discovery
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
- Captive Portal Configuration
- Management up to 1 Router, 2 Switches and 10 EAPs
- Certification
- CE, FCC, RoHS
- Package Contents
- • ER7212PC
- Power Adapter
- Power Cord
- Quick Installation Guide
- System Requirements
- • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10
- MAC OS, NetWare, UNIX or Linux
- Environment
- • Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F)
- Storage Temperature
- -40 °C to 70 °C (-40 °F to 158 °F)
- Operating Humidity
- 10% to 90% non-condensing
- Storage Humidity
- 5% to 90% non-condensing
