- Access Control
- Source/Destination IP Based Access Control
- Filtering
- • WEB Group Filtering §
- URL Filtering
- Web Security §
- ARP Inspection
- • Sending GARP Packets §
- ARP Scanning §
- IP-MAC Binding §
- Attack Defense
- • TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
- Standards and Protocols
- • IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q
- TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
- Interface
- • 1 Fixed Gigabit WAN Port
- 2 Fixed Gigabit LAN Ports
- 2 Changeable Gigabit WAN/LAN Ports
- 1 USB 2.0 Port (Connecting 4G/3G Modem as WAN Backup ‡ )
- Network Media
- • 10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
- EIA/TIA-568 100Ω STP (Max 100m)
- 100BASE-TX
- UTP category 5, 5e cable (Max 100m)
- EIA/TIA-568 100Ω STP (Max 100m)
- 1000BASE-T
- UTP category 5, 5e, 6 cable (Max 100m)
- Fan Quantity
- Fanless
- Button
- Reset Button
- Power Supply
- External 12V/1A DC Adapter
- PoE Budget
- –
- Flash
- 128 MB NAND
- DRAM
- 256 MB DDR
- LED
- PWR, SYS, WAN (Link/Act), LAN (Link/Act), USB
- Dimensions ( W x D x H )
- 6.2 × 4.0 × 1.0 in (158 × 101 × 25mm)
- Protection
- 4 kV surge protection
- Enclosure
- Steel
- Mounting
- Desktop/Wall-mount
- Max Power Consumption
- 7.94 W
- Concurrent Session
- 150,000
- New Sessions /Second
- 2,600
- NAT (Static IP)
- • Upload: 945.77 Mbps
- Download
- 945.56 Mbps
- Bi-Directional
- 1808.29 Mbps
- NAT(DHCP)
- • Upload: 945.93 Mbps
- Download
- 945.43 Mbps
- Bi-Directional
- 1808.11 Mbps
- NAT(PPPoE)
- • Upload: 940.44Mbps
- Download
- 940.52 Mbps
- Bi-Directional
- 1804.27 Mbps
- NAT (L2TP)
- • Upload: 845.64 Mbps
- Download
- 802.65 Mbps
- Bi-Directional
- 931.96 Mbps
- NAT (PPTP)
- • Upload: 771.66 Mbps
- Download
- 874.81 Mbps
- Bi-Directional
- 999.54 Mbps
- 64 Byte Packet Forwarding Rate
- • Upload/Download: 1,402,238 pps
- Bi-Directional
- 1,681,548 pps
- IPsec VPN Throughput
- • ESP-MD5-AES256: 171.26 Mbps
- ESP-SHA1-AES256
- 224.86 Mbps
- ESP-SHA2-AES256
- 248.04 Mbps
- OpenVPN
- • 21.70 Mbps
- L2TP VPN Throughput
- • Unencrypted: 864.65 Mbps
- Encrypted
- 47.11 Mbps
- PPTP VPN Throughput
- • Unencrypted: 703.20 Mbps
- Encrypted
- 76.65 Mbps
- SSL VPN Throughput
- –
- 66 Byte Packet forwarding rate
- • Upload/Download: 954.50 Mbps
- Bi-Directional
- 1130.00 Mbps
- 1,518 Byte Packet forwarding rate
- • Upload/Download: 997.50 Mbps
- Bi-Directional
- 1965.00 Mbps
- WAN Connection Type
- • Static/Dynamic IP
- PPPoE
- PPTP
- L2TP
- Mobile Broadband
- 4G/3G modem for backup via USB port ‡
- MAC Clone
- Modify WAN/LAN MAC Address †
- DHCP
- • DHCP Server/Client
- DHCP Address Reservation
- Multi-net DHCP*
- Multi-IP Interfaces*
- IPv6
- StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough
- VLAN
- 802.1Q VLAN
- IPTV
- IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
- ACL
- IP/Port/Protocol/Domain Name Filtering
- Advanced Routing
- • Static Routing
- Policy Routing
- Bandwidth Control
- IP-based Bandwidth Control
- Load Balance
- • Intelligent Load Balance
- Application Optimized Routing
- Link Backup (Timing § , Failover)
- Online Detection
- NAT
- • One-to-One NAT §
- Multi-Net NAT
- Virtual Server
- Port Triggering §
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG, UPnP
- Security
- • SPI Firewall
- VPN Passthrough
- FTP/H.323/PPTP/SIP/IPsec ALG
- DoS Defence, Ping of Death
- Local Management
- Session Limit
- IP-based Session Limit
- IPsec VPN
- • 20 IPsec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
- IKEv1/v2
- MD5, SHA1 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
- PPTP VPN
- • PPTP VPN Server
- 10 PPTP VPN Clients**
- 16 Tunnels
- PPTP with MPPE Encryption
- L2TP VPN
- • L2TP VPN Server
- 10 L2TP VPN Clients**
- 16 Tunnels
- L2TP over IPSec
- OpenVPN
- • OpenVPN Server*
- 10 OpenVPN Clients* △
- 16 OpenVPN Tunnels*
- Web Authentication
- • No Authentication
- Simple Password*
- Hotspot（Local User / Voucher* / SMS* / Radius*）
- External Radius Sever
- External Portal Sever*
- Facebook*
- Omada App
- Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
- Centralized Management
- • Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Omada Cloud-Based Controller
- Cloud Access
- Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
- Service
- Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
- Maintenance
- • Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3
- Diagnostics (Ping & Traceroute) §
- NTP Synchronize §
- Syslog Support
- Zero-Touch Provisioning
- Yes. Requiring the use of Omada Cloud-Based Controller.
- Management Features
- • Automatic Device Discovery
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
- Captive Portal Configuration
- Certification
- CE, FCC, RoHS
- Package Contents
- • Gigabti VPN Router ER605
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
- System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11, MAC OS, NetWare, UNIX or Linux
- Environment
- • Operating Temperature: 0–40 ℃ (32–104 ℉);
- Storage Temperature
- -40–70 ℃ (-40–158 ℉)
- Operating Humidity
- 10–90% RH non-condensing
- Storage Humidity
- 5–90% RH non-condensing
- รหัสสินค้า (SKU)
- TPL-ER605
- หมวดหมู่
- เราเตอร์
- ประเภทการจัดส่ง
- จัดส่งสินค้าจริง
