Omada AC1200 Gigabit Wi-Fi Gateway
| รุ่น | ER605W |
|---|---|
| Omada App | Yes. |
| Centralized Management | • Omada App• Omada Hardware Controller • Omada Software Controller |
| Management Features | • Automatic Device Discovery• Intelligent Network Monitoring• Abnormal Event Warnings• Unified Configuration• Reboot Schedule• Captive Portal Configuration |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| System Requirements | • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11• MAC OS, NetWare, UNIX or Linux |
| Flash | 128 MB NAND |
| DRAM | 256 MB DDR3 |
| 66 Byte Packet Forwarding Rate | 1,453,489 pps /1,453,489 pps |
| 1,518 Byte Packet forwarding rate | 81,275 pps / 81,275 pps |
| L2TP VPN Throughput | • Unencrypted: 400.3 Mbps• Encrypted: 127.5 Mbps |
| PPTP VPN Throughput | • Unencrypted: 523.6 Mbps • Encrypted: 52.7 Mbps |
| IPsec VPN Throughput (AES256) | • ESP-SHA1-AES256: 175.5 Mbps• ESP-SHA256-AES256: 185.9 Mbps • ESP-SHA384-AES256: 30.9 Mbps • ESP-SHA512-AES256: 30.7 Mbps |
| Wi-Fi Frequency & Signal Rate | • 2.4 GHz: 300 Mbps• 5 GHz: 867 Mbps |
| เสาอากาศ | • 2.4 GHz: 2× 5 dBi non-detachable antennas• 5 GHz: 2× 5 dBi non-detachable antennas |
| Bandwidth Control | IP-Based Bandwidth Control |
| พอร์ตเชื่อมต่อ | • 1× Gigabit WAN Port• 2× Gigabit WAN/LAN Ports• 2× Gigabit LAN Ports |
| WAN Connection Type | • Static IP• Dynamic IP• PPPoE (supports MRU Configuration)• PPTP• L2TP |
| Network Services Enabled by Default | Web ServerManage and configure device through web (HTTP/HTTPS)• Port: 80/443 Protocol: TCP_____________________________________________________TDP ServerDevice discovery• Port: 20003 Protocol: UDP_____________________________________________________DHCP ServerHandle DHCP packets• Port: 67 Protocol: UDP_____________________________________________________DNSHandle DNS packets• Port: 53 Protocol: TCP/UDP |
| Max. Power Consumption | • EU: 9W • US: 10.3W |
| NAT(PPPoE) | 929.9 Mbps /929.2 Mbps |
| Button | Reset Button |
| Advanced Features | • Multiple SSIDs: 16 in total (8 per radio)• Enable/Disable Wireless Radio• Enable/Disable SSID Broadcast• Automatic Channel Selection Algorithm• Transmit Power Control: Adjust transmit Power on dBm• Rate Limit: Based on SSID/Client• Load Balance• Band Steering• RADIUS Accounting• MAC Authentication• Wireless Schedule • Wireless Encryption: WPA/WPA2 Personal, WPA/WPA2 Enterprise |
| Stateful ACL | √ |
| Bridge VLAN | √ |
| VLAN | 802.1Q VLAN |
| ขนาด (กว้าง × ลึก × สูง) | 8.5 × 4.6 × 1.2 in (215 × 117 × 31 mm) |
| Mounting | Desktop/Wall-mounting |
| NAT (Static IP) | 909.3Mbps/937.5 Mbps |
| Certification | CE, FCC |
| อุปกรณ์ในกล่อง | • ER605W• Power Adapter• Ethernet Cable• Quick Installation Guide |
| Environment | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)• Operating Humidity: 10% to 90% non-condensing• Storage Humidity: 5% to 90% non-condensing |
| Access Control | Source/Destination IP Based Access Control |
| DNS Proxy | DNSSEC, DoH, and DoT |
| Filtering | • Web Group Filtering△ • URL Filtering• Web Security△ |
| Attack Defense | • TCP/UDP/ICMP Flood Defense• Block TCP Scan (Stealth FIN/Xmas/Null)• Block Ping from WAN |
| ARP Inspection | • Sending GARP Packets• ARP Scanning△ • IP-MAC Binding |
| GRE | Only in Standalone Mode |
| IPsec VPN | • 6 IPSec VPN Tunnels• LAN-to-LAN, Client-to-LAN• Main, Aggressive Negotiation Mode• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec • Failover• IKE v1/v2• MD5, SHA1, SHA-256, SHA2-384 and SHA2-512 Authentication • Algorithm NAT Traversal (NAT-T)• Dead Peer Detection (DPD)• Perfect Forward Secrecy (PFS) |
| PPTP VPN | • PPTP VPN Server• PPTP VPN Client (6) 6 Tunnels• PPTP with MPPE Encryption |
| L2TP VPN | • L2TP VPN Server L2TP VPN Client (6) 6 Tunnels• L2TP over IPSec |
| OpenVPN | • OpenVPN Server OpenVPN Client (3)• 18 OpenVPN Tunnels• "Certificate + Account" Mode • Full Mode |
| WireGuard VPN | √ |
| แหล่งจ่ายไฟ | 12V DC / 1A Power Adapter |
| LED | • Power, SYS, 2.4G, 5G• WAN (1000/100/10M Link/Act), • WAN/LAN (1000/100/10M Link/Act)• LAN (1000/100/10M Link/Act) |
| Concurrent Session | 50,000 |
| New Sessions /Second | 2,028 |
| NAT(DHCP) | 938.3 Mbps /888.2 Mbps |
| NAT (L2TP) | 346.9 Mbps /337.6 Mbps |
| NAT (PPTP) | 487.1 Mbps/454.3 Mbps |
| GRE | • Unencrypted: 180.1 Mbps • Encrypted: 56.9 Mbps |
| WireGuard VPN | 71.2 Mbps |
| OpenVPN | 16.8 Mbps |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Maintenance | • Web Management Interface• Remote Management• Export & Import Configuration• Diagnostics (Ping & Traceroute)△• NTP Synchronize△• Port Mirroring• Syslog Support |
| MAC Clone | Modify WAN Address |
| DHCP | • DHCP Server• DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization• DHCP Address Reservation• Multi-IP Interfaces• Multi-Net DHCP |
| Quality of Service | √ |
| mDNS Repeater | √ |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Advanced Routing | • Static Routing• Policy Routing• RIP• OSPF |
| Load Balance | • Intelligent Load Balance• Application Optimized Routing• Link Backup(Timing, Failover)• Online Detection |
| NAT | • One-to-One NAT• Multi-Net NAT• Virtual Server• Port Triggering△• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG• UPnP |
| Session Limit | IP-Based Session Limit |
| Web Authentication | • No Authentication• Simple Password• Hotspot (Local User / Voucher§ / SMS§ / Radius§)• External Radius Sever• External Portal Sever§• LDAP |
| ระยะเวลารับประกัน | ตลอดอายุการใช้งาน (สิ้นสุด 3 ปีหลังผู้ผลิตประกาศหยุดผลิต) |
