- Access Control
- Source/Destination IP Based Access Control
- Filtering
- • WEB Group Filtering §
- URL Filtering
- Web Security §
- ARP Inspection
- • Sending GARP Packets §
- ARP Scanning §
- IP-MAC Binding §
- Attack Defense
- • TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
- Standards and Protocols
- • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q， IEEE802.3bz
- TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPN
- Interface
- • 1× 2.5G RJ45 WAN Port
- 1× 2.5G RJ45 WAN/LAN Port
- 1× Gigabit SFP WAN/LAN Port
- 4× Gigabit RJ45 WAN/LAN Ports
- 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)
- Network Media
- • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
- 100BASE-TX
- UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
- 1000BASE-T
- UTP category 5, 5e, 6 cable (Max 100 m)
- 2500BASE-T
- UTP category 5, 5e, 6 cable (Max 100 m)
- Fan Quantity
- Fanless
- Button
- Reset Button
- Power Supply
- 12V/1.5A Adapter
- PoE Budget
- –
- Flash
- 128MB NAND
- DRAM
- 1 GB DDR4
- LED
- PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
- Dimensions ( W x D x H )
- 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
- Protection
- 4 kV surge protection
- Enclosure
- Steel
- Mounting
- Rackmout, Desktop, or Wall Mount
- Max Power Consumption
- 14.2 W (with USB2.0 connected)
- 7.1 W (without USB2.0 connected)
- IPS Throughput
- TCP: 208 Mbps;
- UDP
- 161 Mbps
- DPI Throughput
- TCP: 1823 Mbps;
- UDP
- 1272 Mbps
- WireGuard VPN Throughput
- 343Mbps
- Concurrent Session
- 500,000
- New Sessions /Second
- 6,000
- NAT (Static IP)
- 2365.17 Mbps / 2364.45 Mbps
- NAT(DHCP)
- 2364.45 Mbps / 2366.04 Mbps
- NAT(PPPoE)
- 2347.14 Mbps / 2348.29 Mbps
- NAT (L2TP)
- 1308.86 Mbps / 974.10 Mbps
- NAT (PPTP)
- 1236.27 Mbps / 1280.99 Mbps
- IPsec VPN Throughput
- • ESP-SHA1-AES256: 673.3 Mbps
- ESP-SHA256-AES256
- 650.2 Mbps
- ESP-SHA384-AES256
- 629.3 Mbps
- ESP-SHA512-AES256
- 633.8 Mbps
- L2TP VPN Throughput
- • Unencrypted: 1243.7 Mbps
- Encrypted
- 561.0 Mbps
- SSL VPN Throughput
- 132.24 Mbps
- 66 Byte Packet forwarding rate
- 1832.69 Mbps / 1741.84 Mbps
- 1,518 Byte Packet forwarding rate
- 2461.18 Mbps / 2457.32 Mbps
- WAN Connection Type
- • IPv4_Static IP
- IPv4_Dynamic IP
- IPv4_PPPOE
- IPv4_L2TP
- IPv4_PPTP
- IPv6_PPP
- IPv6_DHCPv6
- IPv6_Static IP
- IPv6_6in4
- IPv6_Pass-Through
- Mobile Broadband
- 4G/3G modem for backup via USB port
- MAC Clone
- Modify WAN/LAN MAC Address †
- DHCP
- • DHCP Server
- DHCPv6 PD Server (only in Standalone Mode)
- DHCP Options Customization
- DHCP Address Reservation
- Multi-IP Interfaces*
- Multi-Net DHCP*
- IPv6
- StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
- VLAN
- 802.1Q VLAN
- IPTV
- IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
- Advanced Routing
- • Static Routing
- Policy Routing
- RIP (only in Standalone Mode)
- OSPF (only in Standalone Mode)
- Bandwidth Control
- • IP/Port-based Bandwidth Control
- Guarantee & Limited Bandwidth
- Load Balance
- • Intelligent Load Balance
- Application Optimized Routing
- Link Backup (Timing § , Failover)
- Online Detection
- NAT
- • One-to-One NAT §
- Multi-Net NAT
- Port Forwarding
- Port Triggering §
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP
- Session Limit
- IP-based Session Limit
- IPsec VPN
- • 100 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm
- IKEv1/v2
- MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
- PPTP VPN
- • PPTP VPN Server
- PPTP VPN Clients (12)
- 60 Tunnels (Shared with L2TP)
- PPTP with MPPE Encryption
- L2TP VPN
- • L2TP VPN Server
- L2TP VPN Clients (12)
- 60 Tunnels (Shared with PPTP)
- L2TP over IPSec
- OpenVPN
- • OpenVPN Server
- OpenVPN Clients (6)
- 66 OpenVPN Tunnels*
- WireGuard VPN
- • 20 Tunnels
- Web Authentication
- • No Authentication
- Simple Password*
- Hotspot (Local User/Voucher*/SMS*/Radius*)
- External Radius Server
- External Portal Server*
- LDAP
- Omada App
- Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Centralized Management
- • Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
- Cloud Access
- Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Service
- Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
- Maintenance
- • Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3*
- Diagnostics (Ping & Traceroute) §
- NTP Synchronize §
- Port Mirroring
- CLI (only in Standalone Mode)
- Syslog Support
- Zero-Touch Provisioning
- Yes. Requires the use of Omada Cloud-Based Controller.
- Management Features
- • Automatic Device Discovery*
- Batch Configuration*
- Batch Firmware Upgrading*
- Intelligent Network Monitoring*
- Abnormal Event Warnings*
- Unified Configuration*
- Reboot Schedule*
- Certification
- CE, FCC, RoHS
- Package Contents
- • ER707-M2
- Power Adapter
- Quick Installation Guide
- Rackmount Kit
- System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
- Environment
- • Operating Temperature: 0–40 ℃ (32–104 ℉);
- Storage Temperature
- -40–70 ℃ (-40–158 ℉)
- Operating Humidity
- 10–90% RH non-condensing
- Storage Humidity
- 5–90% non-condensing
