- Dimensions
- 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
- Managed UniFi Devices
- 200+
- Managed Cameras
- (50) HD, (25) 2K, (15) 4K
- Simultaneous Users Connected
- 2,000+
- Max. WAN Port Count
- 8
- Default WAN Ports
- (1) 10G SFP+, (1) 2.5 GbE RJ45
- Port Layout
- 1 GbE RJ45: 8 (1G/100M/10M), 2.5 GbE RJ45: 1 (2.5G/1G/100M/10M), 10G SFP+: 2 (10G/1G)
- IDS/IPS Throughput
- 5 Gbps
- Form Factor
- Rack mount (1U)
- Redundancy
- Shadow Mode (VRRP) Gateway Failover, DC Power Backup
- Network
- ✓
- Protect
- ✓
- Access
- ✓
- Talk
- ✓
- Connect
- ✓
- Stateful Firewall
- ✓
- Application-Aware Layer 7 Firewall
- ✓
- DPI & Traffic Identification
- ✓
- Zone-Based Firewall Advanced Filtering
- ✓ (Regions, Domains, Apps)
- Content Filtering
- ✓
- Intrusion Prevention (IPS/IDS)
- ✓
- Ad Blocking
- ✓
- IDS/IPS Signatures
- 55,000+ with CyberSecure
- VLAN/Subnet-based Traffic Segmentation
- ✓
- License-Free SD-WAN
- ✓
- Site-to-Site VPN
- Site Magic ✓
- IPsec
- ✓
- OpenVPN
- ✓
- VPN Server
- Identity Endpoint One-Click VPN ✓, Teleport Zero-Configuration VPN ✓, WireGuard ✓, OpenVPN ✓, L2TP ✓
- VPN Client
- OpenVPN ✓, WireGuard ✓
- Multi-WAN Load Balancing
- ✓
- Shadow Mode (VRRP) High Availability
- ✓
- Dynamic Routing
- OSPF ✓, BGP ✓
- Advanced QoS
- ✓
- Multicast DNS (mDNS)
- ✓
- Advanced NAT
- ✓ (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
- Integrated RADIUS Server
- ✓
- RADIUS over TLS (RadSec)
- ✓
- Additional Internet Failover with UniFi LTE Backup
- ✓
- Internet Quality and Outage Reporting
- ✓
- MAC Address Table Size
- 4,000
- Policy-based WAN and VPN Routing
- ✓
- Customizable DHCP Server
- ✓
- IPv6 ISP Support
- ✓
- IGMP Proxy
- ✓
- NVR Storage
- (2) 3.5″ NVR HDD bays, Built-in 128 GB SSD
- Max. Power Consumption
- 60W
- Power Method
- (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz; (1) USP-RPS DC input, 11.5V DC, 8.7A
- Power Supply
- AC/DC, internal, 100W
- Supported Voltage Range
- 100—240V AC
- Processor
- Quad-core ARM® Cortex®-A57 at 2.0 GHz
- System Memory
- 8 GB
- On-board Storage
- 32 GB eMMC, 128 GB SSD (Integrated)
- Weight
- 4.7 kg (10.4 lb)
- Enclosure Material
- Aluminium CNC, SGCC steel
- Mount Material
- SGCC steel
- LCM Display
- 1.3″ touchscreen
- Management
- Ethernet, Bluetooth
- LEDs
- Ethernet ✓, SFP+ ✓, RPS ✓, PSU ✓, HDD ✓
- Button
- (1) Factory-reset
- ESD/EMP Protection
- Air: ± 15kV, Contact: ± 8kV
- Ambient Operating Temperature
- -10 to 40° C (14 to 104° F)
- Ambient Operating Humidity
- 5 to 95% noncondensing
- NDAA Compliant
- ✓
- Certifications
- CE, FCC, IC, Anatel, SRRC
